Comtech EF Data CDM-570L Installation And Operation Manual page 447

CDM-570/570L Satellite Modem with Optional IP Module
Appendix F
F.3.4.24 (ODU,ENABLE, INFO)
HPA: On
Fault Logic: No Summary
This window provides the current configuration of the HPA functions, press ENT.
F.3.4.25 (ODU,ENABLE, INFO)
LNA: On
Fault Logic: No Summary
This window provides the current configuration of the LNA functions, press ENT.
F.3.4.26 (ODU,ENABLE,INFO)
EQUIP-TYPE: KST-2000A
HPA-TYPE: CEFD-SSPA
F.3.4.27 (ODU,ENABLE,INFO)
ASSEMBLY INFO:
AS:11565-4
Note: The blinking cursor is on the M&C. Use the ▲ ▼ keys to view additional
assembly and S/N information for the Up Converter, Down Converter, and HPA.
F.3.4.28 ODU,ENABLE,INFO)
FIRMWARE INFO:
FW:10303-1D
Note: The blinking cursor is on the M&C. Use the ▲ ▼ keys to view additional
firmware information for the Up Converter, Down Converter, and HPA.
HPA
LNA
EQUIP (Equipment)
ASSEMBLY+SN
M&C
SN:001370891
FW (Firmware)
M&C
VER:01.01.05
F–23
Revision 4
MN/CDM570L.IOM
