CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.5.2

(CONFIG, REMOTE) ETHERNET

If Ethernet is selected the following sub menu is displayed:
Ethernet Config: Gateway
Address MAC SNMP
changed using the
▲▼
valid range of addresses is from 1 to 9999.
(CONFIG, REM, SERIAL, BAUD RATE)
If the user selects Baud Rate, the user is presented with the following menu:
Edit the baud rate of the remote control bus, connected locally to the M&C
Local M&C Bus Baud Rate:
19200 Baud
computer. The value is changed using the
press ENTER. Values of 2400, 4800, 9600,19200, 38400 and 57600 baud are
possible.
Note that the asynchronous character format is FIXED at 8 data bits, 1 stop bit,
no parity (8-N-1).
(CONFIG, REMOTE, ETHERNET) GATEWAY
If Gateway is selected the following sub-menu is displayed:
Ethernet IP Gateway:
192.168.001.002
Edit the IP Gateway Address for the Ethernet M&C port for this unit. This is
accomplished by selecting the digit to be edited, using the ◄ ► arrow keys. The
value of the digit is then changed using the
then press ENTER.
(CONFIG, REMOTE, ETHERNET) ADDRESS
If Address is selected the following sub-menu is displayed:
Ether IP Address/Range:
192.168.001.002/24 (◄ ►,▲ ▼)
Edit the IP Address and Range for the Ethernet M&C port for this unit. This is
accomplished by selecting the digit to be edited, using the
value of the digit is then changed using the
then press ENTER.
arrow keys. The user should then press ENTER. The
(▲ ▼,ENTER)
▲ ▼
(◄ ►)
(◄ ►,▲ ▼)
▲ ▼
▲ ▼
6–8
MN/CDM570L.IOM
arrow keys. The user should then
arrow keys. The user should
◄ ► arrow keys. The
arrow keys. The user should
Revision 4
