Danfoss VACON NX All-in-One Application Manual page 99

VACON® NX All-in-One
Application Guide
Index Parameter
VACON NXP drives only
®
P2.3.2.5 INV Delayed DO2
P2.3.2.6 ID Bit Free DO2
DO2 Time Scale
P2.3.2.7
Table 65: Digital Output Signals (Control Panel: Menu M2 -> G2.2.4)
Index Parameter
To avoid function overruns and to ensure flawless operation, make ABSOLUTELY sure that two functions ARE NOT CONNEC-
TED to one and same output.
P2.3.3.1
(1)
Ready
P2.3.3.2
(1)
Run
P2.3.3.3
(1)
Fault
P2.3.3.4
(1)
Inverted fault
P2.3.3.5
(1)
Warning
P2.3.3.6
(1)
External fault
P2.3.3.7
(1)
Reference fault/warning
P2.3.3.8
(1)
Overtemperature warning
P2.3.3.9
(1)
Reverse
P2.3.3.10
(1)
Unrequested direction
P2.3.3.11
(1)
At speed
P2.3.3.12
(1)
Jogging speed
P2.3.3.13
(1)
I/O control place
P2.3.3.14
(1)
External brake control
P2.3.3.15
(1)
External brake control, inverted
Danfoss A/S © 2023.02
Min Max Unit
-
0 1
-
0.0 200.15
0 2 -
Min Default ID Description
N O T I C E
-
0.1 A.1 432
-
0.1 B.1 433
-
0.1 B.2 434
-
0.1 0.1 435
-
0.1 0.1 436
-
0.1 0.1 437
-
0.1 0.1 438
-
0.1 0.1 439
-
0.1 0.1 440
-
0.1 0.1 441
-
0.1 0.1 442
-
0.1 0.1 443
-
0.1 0.1 444
0.1 0.1 445 See
10.190 (ID 446) External Brake Control,
0.1 0.1 446
Multi-purpose Control Application
Default ID
0 1588
0.0 1385
0 1061
10.189 (ID 445) External Brake Control
AB296635287482en-000301 / DPD00903 | 99
Description
0 = No
1 = Yes
-
0 = s
1 = min
2 = h
and
Inverted.
