VACON® NX All-in-One
Application Guide
Index Name
P2.13.1.10 Speed Band
P2.13.2.1 Stator Winding Fault Mode
P2.13.2.2 Line Frequency
P2.13.2.3 Line Frequency Hysteresis
P2.13.2.4.1 Mean Factor
P2.13.2.4.2 Min Factor
P2.13.2.4.3 Max Factor
P2.13.2.4.4 Std Factor
P2.13.2.4.5 Interpolation Type
P2.13.2.5.1 Warning S1 Mode
P2.13.2.5.2 Warning S1 High
P2.13.2.5.3 Warning S1 Delay
P2.13.2.5.4 Warning S2 Mode
P2.13.2.5.5 Warning S2 High
P2.13.2.5.6 Warning S2 Delay
P2.13.2.5.7 Alarm/Fault Mode
124 | Danfoss A/S © 2023.02
Min Max Unit
0.00 10.00 %
0.00 2 -
0.00 100.00 Hz
0.00 10.00 Hz
-10.0 10.0 -
-10.0 10.0 -
-10.0 10.0 -
-10.0 10.0 -
0 1 -
0 2 -
0.00 300.00 %
0 3600 s
0 2 -
0.00 300.00 %
0 3600 s
0 2 -
Multi-purpose Control Application
Default ID Description
4 = Current Std Steady
5 = Voltage Max Steady
6 = Voltage Min Steady
7 = Voltage Mean Steady
8 = Voltage Std Steady
9 = Vibration Max Ramp
10= Vibration Min Ramp
11 = Vibration Mean Ramp
12 = Vibration Std Ramp
13 = Load Max Steady
14 = Load Min Steady
15 = Load Mean Steady
16 = Load Std Steady
17 = Current Counter
18 = Voltage Counter
19 = Vibration Counter
20 = Load Counter
5.00 3510 -
0 3540
0 = No Response
1 = Warnings
2 = Fault + Warnings
50.00 1913 -
1.00 1914 -
1.0 3511 -
0.0 3512 -
0.0 3513 -
0.0 3514 -
1 3515
0 = Constant
1 = Linear
0 3516
0 = Abs. Value
1 = Baseline Offset
2 = Baseline Factor
0.00 3517 -
10 3518 -
0 3519
0 = Abs. Value
1 = Baseline Offset
2 = Baseline Factor
0.00 3720 -
10 3721 -
0 3522
0 = Abs. Value
