VACON® NX All-in-One
Application Guide
ID Monitoring value
7 DC-link voltage
8 Unit temperature
9 Motor temperature
13 AI1
14 AI2
See also 7.4.1 Monitoring Values (Control Panel: Menu M1)
10.387 (ID 853) Fieldbus Process Data Out 2 Selection
Location in the menu: P2.9.4 (Multi-purpose Control Application)
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
To monitor an item, enter the ID number of the item as the value of this parameter.
See 10.386 (ID 852) Fieldbus Process Data Out 1
10.388 (ID 854) Fieldbus Process Data Out 3 Selection
Location in the menu: P2.9.5 (Multi-purpose Control Application)
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
To monitor an item, enter the ID number of the item as the value of this parameter.
See 10.386 (ID 852) Fieldbus Process Data Out 1
10.389 (ID 855) Fieldbus Process Data Out 4 Selection
Location in the menu: P2.9.6 (Multi-purpose Control Application)
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
To monitor an item, enter the ID number of the item as the value of this parameter.
See 10.386 (ID 852) Fieldbus Process Data Out 1
10.390 (ID 856) Fieldbus Process Data Out 5 Selection
Location in the menu: P2.9.7 (Multi-purpose Control Application)
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
To monitor an item, enter the ID number of the item as the value of this parameter.
See 10.386 (ID 852) Fieldbus Process Data Out 1
10.391 (ID 857) Fieldbus Process Data Out 6 Selection
Location in the menu: P2.9.8 (Multi-purpose Control Application)
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
To monitor an item, enter the ID number of the item as the value of this parameter.
See 10.386 (ID 852) Fieldbus Process Data Out 1
10.392 (ID 858) Fieldbus Process Data Out 7 Selection
Location in the menu: P2.9.9 (Multi-purpose Control Application)
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
To monitor an item, enter the ID number of the item as the value of this parameter.
Location in the menu: P2.9.4 (Multi-purpose Control Application)
10.393 (ID 859) Fieldbus Process Data Out 8 Selection
Location in the menu: P2.9.10 (Multi-purpose Control Application)
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
To monitor an item, enter the ID number of the item as the value of this parameter.
Danfoss A/S © 2023.02
ID Monitoring value
28 AI4
31 AO1 (expander board)
32 AO2 (expander board)
37 Active fault 1
45 Motor current (drive independent) given with one decimal point.
for more monitoring values.
Selection.
Selection.
Selection.
Selection.
Selection.
Parameter Descriptions
AB296635287482en-000301 / DPD00903 | 265
