VACON® NX All-in-One
Application Guide
Bit
Value = 0 (FALSE)
Bit 6
Force Ref to Zero
Bit 7
No action
Bit 8
No action
Bit 9
No action
Bit 10
Disable PROFIBUS control
Bit 11
Fieldbus DIN 1=OFF
Bit 12
Fieldbus DIN 2=OFF
Bit 13
Fieldbus DIN 3=OFF
Bit 14
Fieldbus DIN 4=OFF
Bit 15
No Action
9.96 (ID 1169) Shaft Angle
Location in the menu: V1.21.7 (Multi-Purpose Control Application in VACON
This monitoring value shows the shaft angle from the encoder.
9.97 (ID 1170) Shaft Rounds
Location in the menu: V1.21.6 (Multi-Purpose Control Application in VACON
This monitoring value shows the shaft rounds from the encoder.
9.98 (ID 1172) Fault Word 1
Location in the menu: V1.22.13 (Multi-Purpose Control Application in VACON
This monitoring value shows the bit-coded status of the Fault Word 1.
9.99 (ID 1173) Fault Word 2
Location in the menu: V1.22.14 (Multi-Purpose Control Application in VACON
This monitoring value shows the bit-coded status of the Fault Word 2.
9.100 (ID 1174) Alarm Word 1
Location in the menu: V1.22.15 (Multi-Purpose Control Application in VACON
This monitoring value shows the bit-coded status of the Alarm Word.
9.101 (ID 1508) Output Power
Location in the menu: V1.21.24 (Multi-Purpose Control Application in VACON
This monitoring value shows the output power.
9.102 (ID 1601) SB System Status
Location in the menu: V1.23.1 (Multi-Purpose Control Application in VACON
This monitoring value shows the status of the SystemBus.
9.103 (ID 1602) Status Word D2
Location in the menu: V1.23.4.2 (Multi-Purpose Control Application in VACON
This monitoring value shows the status of the Status Word of the Follower drive.
9.104 (ID 1603) Status Word D3
Location in the menu: V1.23.4.3 (Multi-Purpose Control Application in VACON
160 | Danfoss A/S © 2023.02
Value = 1 (TRUE)
Enable Ramp
FAULT RESET (0 -> 1)
Inching 1
Inching 2
Enable PROFIBUS control
Fieldbus DIN 1=ON
Fieldbus DIN 2=ON
Fieldbus DIN 3=ON
Fieldbus DIN 4=ON
No Action
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
Monitoring Value Descriptions
AB296635287482en-000301 / DPD00903
