VACON® NX All-in-One
Application Guide
Table 5: Monitoring Values
Index Monitoring value
V1.1 Output frequency
V1.2 Frequency reference
V1.3 Motor speed
V1.4 Motor current
V1.5 Motor torque
V1.6 Motor shaft power
V1.7 Motor voltage
V1.8 DC-link voltage
V1.9 Unit temperature
V1.10 Motor temperature
V1.11 Analog input 1
V1.12 Analog input 2
V1.13 DIN 1, 2, 3
V1.14 DIN 4, 5, 6
V1.15 DO1, RO1, RO2
V1.16 Analog I
out
V1.17 Multimonitoring items
3.4.2 Basic Parameters (Control Panel: Menu M2 -> G2.1)
Table 6: Basic Parameters G2.1
Index Parameter
P2.1.1 Min frequency
P2.1.2 Max frequency
P2.1.3 Acceleration time 1
P2.1.4 Deceleration time 1
P2.1.5 Current limit
P2.1.6 Nominal voltage of the motor
P2.1.7 Nominal frequency of the motor
P2.1.8 Nominal speed of the motor
Danfoss A/S © 2023.02
Unit Form
Hz #.##
Hz #.##
RPM #
A Varies
% #.#
% #.#
V #.#
V #
°C #
% #.#
V/mA #.##
V/mA #.##
- -
- -
- -
mA #.##
- -
Min Max Unit
0.00 P2.1.2 Hz
P2.1.1 320.00 Hz
0.1 3000.0 s
0.1 3000.0 s
0.1 x I 2 x I A
H H
180 690 V
8.00 320.00 Hz
24 20 000 RPM
Standard Application
ID Description
1 -
25 -
2 -
3 -
4 -
5 -
6 -
7 -
8 -
9 -
13 -
14 -
15 -
16 -
17 -
26 -
- -
Default ID Description
-
0.00 101
-
50.00 102
-
0.0 103
-
0.0 104
-
I 107
L
-
NX2: 230 V 110
NX5: 400 V
NX6: 690 V
-
50.00 111
-
1440 112
AB296635287482en-000301 / DPD00903 | 19
