Danfoss VACON NX All-in-One Application Manual page 136

VACON® NX All-in-One
Application Guide
Index Parameter
P2.2.1.10
(1)
Actual value 2 input
P2.2.1.11 Actual value 1 mini-
mum scale
P2.2.1.12 Actual value 1 maxi-
mum scale
P2.2.1.13 Actual value 2 mini-
mum scale
P2.2.1.14 Actual value 2 maxi-
mum scale
P2.2.1.15 Motor potentiometer
ramp time
P2.2.1.16 Motor potentiometer
frequency reference
memory reset
P2.2.1.17 Motor potentiometer
PID reference memo-
ry reset
P2.2.1.18 B reference scale,
minimum
P2.2.1.19 B reference scale,
maximum
Use the Terminal to Function method (TTF) with these parameters, see
1
Table 93: Analog Input 1 (Control Panel: Menu M2 -> G2.2.2)
Index Parameter
P2.2.2.1
(1)
AI1 signal selection
P2.2.2.2
AI1 filter time
P2.2.2.3
(2)
AI1 signal range
136 | Danfoss A/S © 2023.02
Min Max Unit Default
-
0 5 0
-1600.0 1600.0 % 0.0
-1600.0 1600.0 % 100.0
-1600.0 1600.0 % 0.0
-1600.0 1600.0 % 100.0
0.1 2000.0 Hz/s 10.0
-
0 2 1
-
0 2 0
0.00 320.00 Hz 0.00
0.00 320.00 Hz 0.00
10.626 "Terminal to Function" (TTF) Programming
Min Max
0.1 E.10
0.00 10.00
0 2
Pump and Fan Control Application
ID Description
3 = AI3
4 = AI4
5 = Fieldbus (FBProcessDataIN2)
335 0 = Not used
1 = AI1 (control board)
2 = AI2 (control board)
3 = AI3
4 = AI4
5 = Fieldbus (FBProcessDataIN3)
336 0 = No minimum scaling
337 100 = No maximum scaling
338 0 = No minimum scaling
339 100 = No maximum scaling
-
331
367 0 = No reset
1 = Reset if stopped or powered down
2 = Reset if powered down
370 0 = No reset
1 = Reset if stopped or powered down
2 = Reset if powered down
344 0 = Scaling off
>0 = Scaled min. value
345 0 = Scaling off
>0 = Scaled min. value
Unit Default ID
-
A.1 377
s 0.10 324
-
0 320
AB296635287482en-000301 / DPD00903
Principle).
Description
-
-
0 = 0–10 V (0–20 mA)
1 = 2–10 V (4–20 mA)
2 = Customised
