Index Parameter
P2.2.2 DIN 3 function
P2.2.3
(2)
AI1 signal selection
P2.2.4
(3)
AI1 signal range
P2.2.5 AI1 custom setting minimum
P2.2.6 AI1 custom setting maximum
P2.2.7 AI1 signal inversion
P2.2.8 AI1 signal filter time
P2.2.9
(2)
AI2 signal selection
P2.2.10
(3)
AI2 signal range
P2.2.11 AI2 custom setting minimum
P2.2.12 AI2 custom setting maximum
Danfoss A/S © 2023.02
Min Max Unit Default
-
0 13 1
-
0.1 E.10 A1
-
0 2 0
-160.00 160.00 % 0.00
-160.00 160.00 % 0.00
-
0 1 0
0.00 10.00 s A1
-
0.1 E.10 A.2
-
0 2 1
-160.00 160.00 % 0.00
-160.00 160.00 % 100.00
Local/Remote Control Application
ID Description
Ctrl sgn 1 = Start forward (edge)
Ctrl sgn 2 = Start reverse (edge)
Logic = 6
Ctrl sgn 1 = Start (edge) / Stop
Ctrl sgn 2 = Reverse
Logic = 7
Ctrl sgn 1 = Start (edge) / Stop
Ctrl sgn 2 = Run enable
Logic = 8
Ctrl sgn 1 = Start forward (edge)
Ctrl sgn 2 = Motor potentiometer UP
301 0 = Not used
1 = Ext. fault, closing cont.
2 = Ext. fault, opening cont.
3 = Run enable
4 = Acc./Dec. time selection
5 = Force cp. to I/O
6 = Force cp. to keypad
7 = Force cp. to fieldbus
8 = Reverse
9 = Jogging speed
10 = Fault reset
11 = Acc./Dec. operation prohibit
12 = DC Braking command
13 = Motor potentiometer DOWN
-
377
320 0 = 0–10 V (0–20 mA)
1 = 2–10 V (4–20 mA)
2 = Custom setting range
-
321
-
322
323 0 = Not inverted
1 = Inverted
-
324
-
388
325 0 = 0–10 V (0–20 mA)
1 = 2–10 V (4–20 mA)
2 = Custom setting range
-
326
-
327
