6.4 Parameter Lists for PID Control Application

6.4.1 Monitoring Values (Control Panel: Menu M1)

The monitoring values are the actual values of parameters and signals as well as statuses and measurements. Monitoring values
cannot be edited.
The monitoring values V1.19 to V1.22 are available with the PID control application only.
Table 35: Monitoring Values
Index Monitoring value
V1.1 Output frequency
V1.2 Frequency reference
V1.3 Motor speed
V1.4 Motor current
V1.5 Motor torque
V1.6 Motor shaft power
V1.7 Motor voltage
V1.8 DC-link voltage
V1.9 Unit temperature
V1.10 Motor temperature
V1.11 Analog input 1
V1.12 Analog input 2
V1.13 Analog input 3
V1.14 Analog input 4
V1.15 DIN 1, 2,3
V1.16 DIN 4, 5, 6
V1.17 DO1, RO1, RO2
V1.18 Analog I
out
V1.19 PID Reference
V1.20 PID Actual value
V1.21 PID Error value
V1.22 PID Output
V1.23 Special display for actual value
V1.24 PT-100 Temperature
G1.25 Monitoring items
V1.26.1 Current
Danfoss A/S © 2023.02
Unit Form ID
Hz #.## 1
Hz #.## 25
RPM # 2
A Varies 3
% #.# 4
% #.# 5
V #.# 6
V # 7
°C # 8
% #.# 9
V/mA #.## 13
V/mA #.## 14
- - 27
- - 28
- - 15
- - 16
- - 17
mA #.## 26
% - 20
% - 21
% - 22
% - 23
- - 29
ºC #.# 42
- - -
A Varies 1113
