10.202 (ID 458) Autochange 1/Auxiliary Drive 1 Control
Location in the menu:P2.3.1.27 (Pump and Fan Control Application)
Use this parameter to select a digital output for the autochange/auxiliary drive status.
Default programming: B.1
10.203 (ID 459) Autochange 2/Auxiliary Drive 2 Control
Location in the menu:P2.3.1.28 (Pump and Fan Control Application)
Use this parameter to select a digital output for the autochange/auxiliary drive status.
TTF programming method must be applied to this parameter (see
Control signal for autochange/auxiliary drive 2.
Default programming: B.2
10.204 (ID 460) Autochange 3/Auxiliary Drive 3 Control
Location in the menu:P2.3.1.29 (Pump and Fan Control Application)
Use this parameter to select a digital output for the autochange/auxiliary drive status.
TTF programming method must be applied to this parameter (see
Control signal for autochange/auxiliary drive 3. If three (or more) auxiliary drives are used, we recommend connecting number 3,
too, to a relay output. Since the OPTA2 board only has two relay outputs, it is recommended to purchase an I/O expander board
with extra relay outputs (for example, VACON
10.205 (ID 461) Autochange 4/Auxiliary Drive 4 Control
Location in the menu:P2.3.1.30 (Pump and Fan Control Application)
Use this parameter to select a digital output for the autochange/auxiliary drive status.
TTF programming method must be applied to this parameter (see
Control signal for autochange/auxiliary drive 4. If three (or more) auxiliary drives are used, we recommend connecting number 3
and 4, too, to a relay output. Since the OPTA2 board only has two relay outputs, it is recommended to purchase an I/O expander
board with extra relay outputs (for example, VACON
10.206 (ID 462) Autochange 5 Control
Location in the menu:P2.3.1.31 (Pump and Fan Control Application)
Use this parameter to select a digital output for the autochange status.
TTF programming method must be applied to this parameter (see
Control signal for autochange drive 5.
10.207 (ID 463) Analog Input Supervision Limit
Location in the menu:P2.3.1.22 (Pump and Fan Control Application)
Use this parameter to select a digital output for the analog input supervision status.
TTF programming method must be applied to this parameter (see
The selected analog input signal goes beyond the set supervision limits (see parameters ID 372, ID 373, and ID 374).
10.208 (ID 464) Analog Output 1 Signal Selection
Location in the menu:
• P2.3.1 (Standard Application, Local/Remote Control Application, Multi-step Speed Control Application, PID Control Application)
• P2.3.5.1 (Multi-purpose Control Application)
• P2.3.3.1 (Pump and Fan Control Application)
Use this parameter to connect the analog output signal 1 to the selected analog output.
The signal selection is done with "Terminal to Function" (TTF) programming. See
Principle.
10.209 (ID 471) Analog Output 2 Signal Selection
Location in the menu:
