Danfoss VACON NX All-in-One Application Manual page 93

VACON® NX All-in-One
Application Guide
Index Parameter
P2.2.1.2
(1)
Motor potentiometer
ramp time
P2.2.1.3
(1)
Motor potentiometer
frequency reference
memory reset
P2.2.1.4
(1)
Adjust input
P2.2.1.5 Adjust minimum
P2.2.1.6 Adjust maximum
P2.2.1.7 Inversion control
Parameter value can only be changed after the AC drive has been stopped.
1
Table 57: Analog Input 1 (Control Panel: Menu M2 -> G2.2.2)
Index Parameter
P2.2.2.1
(1)
AI1 signal selection
P2.2.2.2
AI1 filter time
P2.2.2.3
(2)
AI1 signal range
P2.2.2.4
AI1 custom minimum setting
P2.2.2.5 AI1 custom maximum setting
P2.2.2.6 AI1 reference scaling, minimum value
P2.2.2.7
AI1 reference scaling, maximum value
P2.2.2.8
AI1 joystick hysteresis
Danfoss A/S © 2023.02
Min Max Unit Default
0.1 2000.0 Hz/s 10.0
-
0 2 1
-
0 5 0
0.0 100.0 % 0.0
0.0 100.0 % 0.0
Min
0.1
0.00
0
-160.00
-160.00
0.00
0.00
0.00
Multi-purpose Control Application
ID Description
Ctrl sgn 2 = Enable pulse
-
331
367 0 = No reset
1 = Reset if stopped or powered down
2 = Reset if powered down
493 0 = Not used
1 = AI1
2 = AI2
3 = AI3
4 = AI4
5 = Fieldbus (see group G2.9)
-
494
-
495
1091 B00 = +1 = Invert External fault 1
B01 = +2 = Invert External fault 2
B06 = +64 = Invert Ambient Temperature Monitor
B07 = +128 = Invert Input Switch
B010 = +1024 = Invert Klixon 1
B011 = +2048 = Invert Klixon 2
Max Unit Default
-
E.10 A.1
320.00 s 0.10
-
3 0
160.00 % 0.00
160.00 % 100.00
320.00 Hz 0.00
320.00 Hz 0.00
20.00 % 0.00
AB296635287482en-000301 / DPD00903 | 93
ID Description
-
377
324
320 0 = 0–10 V (0–20 mA)
1 = 2–10 V (4–20 mA)
2 = -10V...+10 V
3 = Custom range
-
321
-
322
-
303
-
304
-
384
