Index Parameter
P2.3.8 RO1 function
P2.3.9 RO2 function
P2.3.10 Output frequency limit 1 super-
vision
P2.3.11 Output frequency limit 1; Su-
pervised value
P2.3.12 Output frequency limit 2 super-
vision
P2.3.13 Output frequency limit 2; Su-
pervision value
P2.3.14 Torque limit supervision func-
tion
P2.3.15 Torque limit supervision value
P2.3.16 Reference limit supervision
function
P.2.3.17 Reference limit supervision val-
ue
P2.3.18 External brake Off-delay
P2.3.19 External brake On-delay
P2.3.20 Frequency converter tempera-
ture limit supervision
38 | Danfoss A/S © 2023.02
Min Max Unit Default
-
0 22 2
-
0 22 3
-
0 2 0
0.00 320.00 Hz 0.00
-
0 2 0
0.00 320.00 Hz 0.00
-
0 2 0
-300.0 300.0 % 0.0
-
0 2 0
0.0 100.0 % 0.0
0.0 100.0 s 0.5
0.0 100.0 s 1.5
-
0 2 0
Local/Remote Control Application
ID Description
9 = Reversed
10 = Jogging speed selected
11 = At speed
12 = Mot. regulator active
13 = OP freq. limit 1 superv.
14 = OP freq. limit superv.2
15 = Torque limit superv.
16 = Ref. limit superv.
17 = Ext. brake control
18 = Control place: I/O
19 = AC drive temp. limit superv.
20 = Unrequested rotation direction
21 = Ext. brake control inverted
22 = Thermistor fault/warn.
See P2.3.7.
313
See P2.3.7.
314
315 0 = No limit
1 = Low limit supervision
2 = High limit supervision
-
316
346 0 = No limit
1 = Low limit supervision
2 = High limit supervision
-
347
348 0 = No
1 = Low limit
2 = High limit
-
349
350 0 = No
1 = Low limit
2 = High limit
-
351
-
352
-
353
354 0 = No
1 = Low limit
