Protections (Control Panel: Menu M2 -> G2.7) - Danfoss VACON NX All-in-One Application Manual

VACON® NX All-in-One
Application Guide
Index Parameter
P2.6.14.11 Start-up torque
P2.6.14.12 Start-up torque FWD
P2.6.14.13 Start-up torque REV
P2.6.14.15 Encoder filter time
P2.6.14.17 Current control P gain
Identification parameter group 2.6.15
P2.6.15.1 Speed step
Parameter value can only be changed after the AC drive has been stopped.
1
4.4.8 Protections (Control Panel: Menu M2 -> G2.7)
Table 22: Protections, G2.7
Index Parameter
P2.7.1 Response to 4 mA reference fault
P2.7.2 4 mA reference fault frequency
P2.7.3 Response to external fault
P2.7.4 Input phase supervision
P2.7.5 Response to undervoltage fault
P2.7.6 Output phase supervision
P2.7.7 Earth fault protection
P2.7.8 Thermal protection of the motor
P2.7.9 Motor ambient temperature factor
P2.7.10 Motor cooling factor at zero speed
42 | Danfoss A/S © 2023.02
Min Max Unit Default
-
0 3 0
-300.0 300.0 % 0.0
-300.0 300.0 % 0.0
0.0 100 ms 0.0
0.00 100.00 % 40.00
-
-50.0 50.0 0.0
Min Max Unit
-
0 5
0.00 P2.1.2 Hz
-
0 3
-
0 3
-
0 1
-
0 3
-
0 3
-
0 3
-100.0 100.0 %
0.0 150.0 %
Local/Remote Control Application
ID Description
621 0 = Not used
1 = Torque memory
2 = Torque reference
3 = Start-up torque fwd/rev
-
633
-
634
-
618
-
617
-
1252
Default ID Description
0 700 0 = No response
1 = Warning
2 = Warning+Previous Freq.
3 = Wrng+Preset- Freq 2.7.2
4 = Fault, stop acc. to 2.4.7
5 = Fault, stop by coasting
-
0.00 728
2 701 0 = No response
1 = Warning
0 730
2 = Fault, stop acc. to 2.4.7
3 = Fault, stop by coasting
0 727 0 = Fault stored in history
1 = Fault not stored
2 702 0 = No response
1 = Warning
2 703
2 = Fault, stop acc. to 2.4.7
3 = Fault, stop by coasting
2 704
-
0.0 705
-
40.0 706
AB296635287482en-000301 / DPD00903
