10.616 (ID 3586) Load Alarm/Fault Low
Location in the menu: P2.13.5.2.12 (Multi-purpose Control Application)
Use this parameter to set the threshold value for computing the alarm/fault low notification threshold. Threshold value range varies
based on warning mode selection. This limit is not used when value is zero.
10.617 (ID 3587) Vibration Input
Location in the menu: P2.13.4.1 (Multi-purpose Control Application)
Use this parameter to select the analog input to vibration.

10.618 Keypad Control Parameters

Unlike the other parameters described in this manual, these parameters are located in the M3 menu of the control panel. The fre-
quency and torque reference parameters do not have an ID number.
10.618.1 (ID 114) Stop Button Activated
Location in the menu:
• P3.4 (Basic Application, Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application, PID
Control Application, Multi-Purpose Control Application)
• P3.6 (Pump and Fan Control Application)
Use this parameter to enable the stop button on the keypad.
To make the Stop button a "hotspot" which always stops the drive regardless of the selected control place, give this parameter the
value 1.
See also parameter ID 125.
10.618.2 (ID 125) Control Place
Location in the menu: P3.1
Use this parameter to select the control place.
For more information, see the User manual product.
Pushing the Start button for 3 s selects the control panel as the active control place and copies the Run status information (Run/
Stop, direction, and reference).
10.618.3 (ID 123) Keypad Direction
Location in the menu: P3.3
Use this parameter to set the rotation direction of the motor when the control place is keypad.
Selection Number Selection Name
0 Forward
1 Reverse
For more information, see the User manual of the product.
10.618.4 R3.2 Keypad Reference
Location in the menu: R3.2
The frequency reference can be adjusted from the keypad with this parameter.
The output frequency can be copied as the keypad reference by pushing the Stop button for 3 s on any of the pages of menu M3.
For more information, see the User Manual of the product.
10.618.5 (ID 167) PID Reference 1
Location in the menu: P3.4 (PID Control Application, Pump and Fan Control Application)
Use this parameter to set the reference value of the PID controller.
The PID controller keypad reference can be set between 0–100%. This reference value is the active PID reference if parameter ID 332
= 2.
