8.4.2 Basic Parameters (Control Panel: Menu M2 -> G2.1)
Table 91: Basic Parameters G2.1
Index Parameter
P2.1.1 Min frequency
P2.1.2 Max frequency
P2.1.3 Acceleration time 1
P2.1.4 Deceleration time 1
P2.1.5 Current limit
P2.1.6
(1)
Nominal voltage of the motor
P2.1.7
(1)
Nominal frequency of the motor
P2.1.8
(1)
Nominal speed of the motor
P2.1.9
(1)
Nominal current of the motor
P2.1.10
(1)
Motor cos phi
P2.1.11
(1)
PID controller reference signal
(Place A)
P2.1.12 PID controller gain
P2.1.13 PID controller I-time
P2.1.14 PID controller D-time
P2.1.15 Sleep frequency
P2.1.16 Sleep delay
P2.1.17 Wake up level
P2.1.18 Wake up function
134 | Danfoss A/S © 2023.02
Min Max Unit Default
0.00 P2.1.2 Hz 0.00
P2.1.1 320.00 Hz 50.00
0.1 3000.0 s 1.0
0.1 3000.0 s 1.0
0.1 x I 2 x I A I
H H L
180 690 V NX2: 230 V
NX5: 400 V
NX6: 690 V
8.00 320.00 Hz 50.00
24 20 000 RPM 1440
0.1 x I 2 X I A I
H H H
-
0.30 1.00 0.85
-
0 6 4
0.0 1000.0 % 100.0
0.00 320.00 s 1.00
0.00 10.00 s 0.00
0 P2.1.2 Hz 10.00
0 3600 s 30
0.0 1000.0 % 25.0
0 3 0
Pump and Fan Control Application
ID Description
-
101
-
102
-
103
-
104
-
107
-
110
-
111
-
112
-
113
-
120
332 0 = AI1
1 = AI2
2 = AI3
3 = AI4
4 = PID ref from Keypad control
page, P3.4
5 = PID ref. from fieldbus (FBPro-
cessDataIN1)
6 = Motor potentiometer
-
118
-
119
-
132
-
1016
-
1017
-
1018
1019 0 = Wake-up at fall below wake-up
level (P2.1.17)
1 = Wake-up at exceeded wake-up
level (P2.1.17)
2 = Wake-up at fall below wake-up
level (P3.4/3.5)
