6.4.4 Output Signals (Control Panel: Menu M2 -> G2.3)
Table 38: Output Signals, G2.3
Index Parameter
P2.3.1
(1)
Analog output 1 signal selec-
tion
P2.3.2 Analog output function
P2.3.3 Analog output filter time
P2.3.4 Analog output inversion
P2.3.5 Analog output minimum
P2.3.6 Analog output scale
P2.3.7 Digital output 1 function
P2.3.8 RO1 function
P2.3.9 RO2 function
Danfoss A/S © 2023.02
Min Max Unit Default
-
0.1 E.10 A.1
-
0 14 1
0.00 10.00 s 1.00
-
0 1 0
-
0 1 0
10 1000 % 100
-
0 23 1
-
0 23 2
-
0 23 3
PID Control Application
ID Description
-
464
307 0 = Not used
1 = Output freq. (0–f )
max
2 = Freq. reference (0–f
max
3 = Motor speed (0–Motor nominal speed)
4 = Motor current (0–I
nMotor
5 = Motor torque (0–T
nMotor
6 = Motor power (0–P
nMotor
7 = Motor voltage (0–U
nMotor
8 = DC-link volt (0–1000 V)
9 = PID controller ref. value
10 = PID contr. act. value 1
11 = PID contr. act. value 2
12 = PID contr. error value
13 = PID controller output
14 = PT100 temperature
308 0 = No filtering
309 0 = Not inverted
1 = Inverted
310 0 = 0 mA (0 V)
1 = 4 mA (2 V)
-
311
312 0 = Not used
1 = Ready
313
2 = Run
3 = Fault
314
4 = Fault inverted
5 = AC drive overheat warning
6 = Ext. fault or warning
7 = Ref. fault or warning
8 = Warning
9 = Reversed
10 = Preset speed 1
11 = At speed
12 = Mot. regulator active
13 = OP freq. limit superv. 1
14 = OP freq. limit superv.2
15 = Torque limit superv.
16 = Ref. limit superv.
17 = Ext. brake control
18 = Control place: I/O
