VACON® NX All-in-One
Application Guide
Table 114: Baseline Status
Bit Signal
0 Baseline Run Not Started
1 Baseline Running
2 Baseline Running 10%
3 Baseline Running 20%
4 Baseline Running 30%
5 Baseline Running 40%
6 Baseline Running 50%
7 Baseline Running 60%
8 Baseline Running 70%
9 Baseline Running 80%
10 Baseline Running 90%
11 Baseline Run Completed
12 Baseline Run Failed
13 Manual run before baseline run is completed
14 Manual run after baseline run completed
15 -
9.135 (ID 3623) Vibration
Location in the menu: V1.24.3.1 (Multi-Purpose Control Application in VACON
This monitoring value shows the vibration when condition-based monitoring is activated.
9.136 (ID 3624) Vibration Threshold Value
Location in the menu: V1.24.3.2 (Multi-Purpose Control Application in VACON
This monitoring value shows the threshold value after interpolating.
9.137 (ID 3625) Vibration S1 High Threshold
Location in the menu: V1.24.3.3 (Multi-Purpose Control Application in VACON
This monitoring value shows the warning S1 high threshold value.
9.138 (ID 3626) Vibration S2 High Threshold
Location in the menu: V1.24.3.4 (Multi-Purpose Control Application in VACON
This monitoring value shows the warning S2 high threshold value.
9.139 (ID 3627) Vibration Alarm High Threshold
Location in the menu: V1.24.3.5 (Multi-Purpose Control Application in VACON
This monitoring value shows the alarm/fault high threshold value.
9.140 (ID 3628) Load Threshold Value
Location in the menu: V1.24.4.2 (Multi-Purpose Control Application in VACON
This monitoring value shows the threshold value after interpolating.
Danfoss A/S © 2023.02
Monitoring Value Descriptions
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
