Index Parameter
P2.3.10 Output frequency limit 1 super-
vision
P2.3.11 Output frequency limit 1; Su-
pervised value
P2.3.12 Output frequency limit 2 super-
vision
P2.3.13 Output frequency limit 2; Su-
pervision value
P2.3.14 Torque limit supervision func-
tion
P2.3.15 Torque limit supervision value
P2.3.16 Reference limit supervision
function
P2.3.17 Reference limit supervision val-
ue
P2.3.18 External brake Off-delay
P2.3.19 External brake On-delay
P2.3.20 Frequency converter tempera-
ture limit supervision
P2.3.21 Frequency converter tempera-
ture limit value
P2.3.22 Analogue output 2 scaling
P2.3.23
Analogue output 2 function
P2.3.24
Analog output 2 filter time
P2.3.25
Analog output 2 inversion
70 | Danfoss A/S © 2023.02
Min Max Unit Default
-
0 2 0
0.00 320.00 Hz 0.00
-
0 2 0
0.00 320.00 Hz 0.00
-
0 2 0
-300.0 300.0 % 100.0
-
0 2 0
0.0 100.0 % 0.0
0.0 100.0 s 0.5
0.0 100.0 s 1.5
-
0 2 0
-10 100 °C 40
-
0.1 E.10 0.1
-
0 14 4
0.00 10.00 s 1.00
-
0 1 0
PID Control Application
ID Description
19 = AC drive temp. limit superv.
20 = Unrequested rotation direction
21 = Ext. brake control inverted
22 = Thermistor fault/warn.
23 = Fieldbus DIN 1
315 0 = No limit
1 = Low limit supervision
2 = High limit supervision
-
316
346 0 = No limit
1 = Low limit supervision
2 = High limit supervision
-
347
348 0 = No
1 = Low limit
2 = High limit
-
349
350 0 = No
1 = Low limit
2 = High limit
-
351
-
352
-
353
354 0 = No
1 = Low limit
2 = High limit
-
355
-
471
472 As parameter 2.3.2
473 0 = No filtering
474 0 = Not inverted
