P2.4.6 Start function
P2.4.7 Stop function
P2.4.8 DC braking current
P2.4.9 DC braking time at stop
P2.4.10 Frequency to start DC braking during
ramp stop
P2.4.11 DC braking time at start
P2.4.12 Flux brake
P2.4.13 Flux braking current
8.4.6 Prohibit Frequency Parameters (Control Panel: Menu M2 -> G2.5)
Table 104: Prohibit Frequency Parameters, G2.5
Index Parameter
P2.5.1 Prohibit frequency range 1 low limit
P2.5.2 Prohibit frequency range 1 high limit
P2.5.3 Prohibit frequency range 2 low limit
P2.5.4 Prohibit frequency range 2 high limit
P2.5.5 Prohibit frequency range 3 low limit
P2.5.6 Prohibit frequency range 3 high limit
P2.5.7 Prohibit acc./dec. ramp
8.4.7 Motor Control Parameters (Control Panel: Menu M2 ->G2.6)
Table 105: Motor Control Parameters, G2.6
Index Parameter
P2.6.1
(1)
Motor control mode
144 | Danfoss A/S © 2023.02
Min Max Unit Default
-
0 2 0
-
0 3 0
0.00 I A 0.7 x I
L
0.00 600.00 s 0.00
0.10 10.00 Hz 1.50
0.00 600.00 s 0.00
-
0 1 0
0.00 I A I
L H
Min Max
-1.00 320.00
0.00 320.00
0.00 320.00
0.00 320.00
0.00 320.00
0.00 320.00
0.1 10.0
Min Max Unit Default
-
0 1 0
Pump and Fan Control Application
ID Description
4 = Used when running (no testing)
505 0 = Ramp
1 = Flying start
2 = Conditional flying start
506 0 = Coasting
1 = Ramp
2 = Ramp+Run enable coast
3 = Coast+Run enable ramp
-
507
H
508 0 = DC brake is off at stop
-
515
516 0 = DC brake is off at start
520 0 = Off
1 = On
-
519
Unit Default ID
Hz 0.00 509
Hz 0.00 510
Hz 0.00 511
Hz 0.00 512
Hz 0.00 513
Hz 0.00 514
x 1.0 518
ID Description
600 0 = Frequency control
AB296635287482en-000301 / DPD00903
Description
0 = Not used
0 = Not used
0 = Not used
0 = Not used
0 = Not used
0 = Not used
-
