7.4.6 Prohibit Frequency Parameters (Control Panel: Menu M2 -> G2.5)
Table 71: Prohibit Frequency Parameters, G2.5
Index Parameter
P2.5.1 Prohibit frequency range 1 low limit
P2.5.2 Prohibit frequency range 1 high limit
P2.5.3 Prohibit frequency range 2 low limit
P2.5.4 Prohibit frequency range 2 high limit
P2.5.5 Prohibit frequency range 3 low limit
P2.5.6 Prohibit frequency range 3 high limit
P2.5.7 Prohibit acc./dec. ramp
7.4.7 Motor Control Parameters, VACON® NXS (Control Panel: Menu M2 -> G2.6)
Table 72: Motor Control Parameters, VACON
Index Parameter
P2.6.1
Motor control mode
P2.6.2
U/f optimisation
P2.6.3
U/f ratio selection
P2.6.4
Field weakening point
P2.6.5
Voltage at field weakening point
P2.6.6
U/f curve midpoint frequency
P2.6.7
U/f curve midpoint voltage
Danfoss A/S © 2023.02
Min Max Unit
0 1205 V
Min
-1.00
0.00
0.00
0.00
0.00
0.00
0.1
NXS, G2.6
®
Min Max
0 2
0 1
0 3
8.00 320.00
10.00 200.00
0.00 P2.6.4
0.00 100.00
Multi-purpose Control Application
Default ID Description
2 = Brakechopper Level
1267
Varies 500 V unit: 567 Vdc
669 V unit: 836 Vdc
Max Unit Default
320.00 Hz 0.00
320.00 Hz 0.00
320.00 Hz 0.00
320.00 Hz 0.00
320.00 Hz 0.00
320.00 Hz 0.00
10.0 x 1.0
Unit Default ID
-
0 600
-
0 109
-
0 108
Hz 50.00 602
% 100.00 603
Hz 50.00 604
% 100.00 605
AB296635287482en-000301 / DPD00903 | 105
ID Description
509 0 = Not used
510 0 = Not used
511 0 = Not used
512 0 = Not used
513 0 = Not used
514 0 = Not used
-
518
Description
0 = Frequency control
1 = Speed control
2 = Open loop torque control
0 = Not used
1 = Automatic torque boost
0 = Linear
1 = Squared
2 = Programmable
3 = Linear with flux optim.
-
-
-
-
