VACON® NX All-in-One
Application Guide
10.43 (ID 145) AI3 Custom Setting Maximum
Location in the menu: P2.2.4.5 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to adjust the scaling of the analog input signal between -160%...160% freely.
Set the custom minimum and maximum levels for the AI3 signal within -160...160%. Example: Min 40%, Max 80% = 8–16 mA.
10.44 (ID 151) AI3 Signal Inversion
Location in the menu:
• P2.2.40 (PID Control Application)
• P2.2.4.6 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to invert the analog input signal.
10.45 (ID 152) AI4 Signal Selection
Location in the menu:
•
P2.2.42 (PID Control Application)
•
P2.2.5.1 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to connect the AI signal to the analog input of your selection.
TTF programming method must be applied to this parameter (see
See 10.39 (ID 141) AI3 Signal
10.46 (ID 153) AI4 Filter Time
Location in the menu:
• P2.2.45 (PID Control Application)
• P2.2.5.2 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to filter out disturbances in the analog input signal.
See parameter 10.40 (ID 142) AI3 Signal Filter
10.47 (ID 154) AI4 Signal Range
Location in the menu:
• P2.2.43 (PID Control Application)
• P2.2.5.3 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to change the range of the analog signal.
See ID 143.
10.48 (ID 155) AI4 Custom Setting Minimum
Location in the menu: P2.2.5.4 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to adjust the scaling of the analog input signal between -160%...160% freely.
See ID 144.
10.49 (ID 156) AI4 Custom Setting Maximum
Location in the menu: P2.2.5.5 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to adjust the scaling of the analog input signal between -160%...160% freely.
TTF programming method must be applied to this parameter (see
See ID 145.
10.50 (ID 162) AI4 Signal Inversion
Location in the menu:
•
P2.2.44 (PID Control Application)
•
P2.2.5.6 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to invert the analog input signal.
See ID 151.
Danfoss A/S © 2023.02
Selection.
Time.
10.626 "Terminal to Function" (TTF) Programming
10.626 "Terminal to Function" (TTF) Programming
AB296635287482en-000301 / DPD00903 | 179
Parameter Descriptions
Principle).
Principle).
