VACON® NX All-in-One
Application Guide

4.3 Control Signal Logic in Local/Remote Control Application

DIN6
2.1.14 Fieldbus Ctrl reference
2.1.13 Keypad Ctrl reference
2.1.12 I/O B reference
2.1.11 I/O A reference
R3.2 Keypad reference
AI1
AI2
Up
Motor
Down
potentiometer
Reference from fieldbus
Start/Stop from fieldbus
Direction from fieldbus
Start forward
DIN1
(programmable)
Start reverse
DIN2
(programmable)
Start forward
DIN4
(programmable)
Start reverse
DIN5
(programmable)
Fault reset input (programmable)
DIN3
Illustration 10: Control Signal Logic of the Local/Remote Control Application

4.4 Parameter Lists for Local/Remote Control Application

4.4.1 Monitoring Values (Control Panel: Menu M1)

The monitoring values are the actual values of parameters and signals as well as statuses and measurements. Monitoring values
cannot be edited.
32 | Danfoss A/S © 2023.02
A
Programmable
Start/Stop and
reverse logic A
B
A
Programmable
Start/Stop and
reverse logic B
B
3.3 Keypad direction
2.1.15 Jogging speed ref.
A
B
Start/Stop buttons
Reset button
Start/Stop
Reverse
≥ 1
Local/Remote Control Application
3.1 Control
place
Internal
frequency ref.
Internal Start/Stop
Internal reverse
Internal fault reset
AB296635287482en-000301 / DPD00903
