VACON® NX All-in-One
Application Guide
This monitoring value shows why ready state is prevented.
Table 112: Prevent MC Ready
Bit Signal
b0 Endat option board (OPTBB, OPTBE) communication is not initialized after power-up.
b1 Drive sync master has wrong modulator or 1000 ms task parameters are not initialized
b2 Drive sync follower delay is active
b3 Drive sync failure in software modulator double period mode
b4 Charge switch delay is active
b5 AFE fast run disable through ENC C1 is active
b6 100 ms task not executed
b7 -
b8 -
b9 -
b10 -
b11 -
b12 -
b13 -
b14 -
b15 -
9.111 (ID 1615) Status Word D1
Location in the menu: V1.23.4.1 (Multi-Purpose Control Application in VACON
This monitoring value shows the status of the Status Word of the Follower drive.
9.112 (ID 1616) Motor Current D1
Location in the menu: V1.23.3.1 (Multi-Purpose Control Application in VACON
This monitoring value shows the measured current of the motor.
9.113 (ID 3601) Baseline Data Element 1
Location in the menu: V1.24.1.2 (Multi-Purpose Control Application in VACON
This monitoring value shows the baseline data. The baseline data is selected using the baseline data selector.
9.114 (ID 3602) Baseline Data Element 2
Location in the menu: V1.24.1.3 (Multi-Purpose Control Application in VACON
This monitoring value shows the baseline data. The baseline data is selected using the baseline data selector.
9.115 (ID 3603) Baseline Data Element 3
Location in the menu: V1.24.1.4 (Multi-Purpose Control Application in VACON
This monitoring value shows the baseline data. The baseline data is selected using the baseline data selector.
9.116 (ID 3604) Baseline Data Element 4
Location in the menu: V1.24.1.5 (Multi-Purpose Control Application in VACON
162 | Danfoss A/S © 2023.02
Monitoring Value Descriptions
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
