VACON® NX All-in-One
Application Guide
This monitoring value shows the actual speed of the motor that is sent to the fieldbus.
9.88 (ID 875) FB Speed Reference
Location in the menu: V1.22.2 (Multi-Purpose Control Application in VACON
This monitoring value shows the fieldbus frequency reference as a percentage of minimum frequency to maximum frequency.
9.89 (ID 1113) Current
Location in the menu:
• V1.21.1 (Multi-Purpose Control Application in VACON
• V1.26.1 (PID Control Application, Pump and Fan Control Application)
This monitoring value shows the unfiltered motor current.
9.90 (ID 1124) Encoder 1 Frequency
Location in the menu: V1.21.5 (Multi-Purpose Control Application in VACON
This monitoring value shows the input frequency of the encoder.
9.91 (ID 1125) Torque
Location in the menu:
• V1.21.2 (Multi-Purpose Control Application)
• V1.26.2 (PID Control Application, Pump and Fan Control Application)
This monitoring value shows the unfiltered motor torque.
9.92 (ID 1131) Final Frequency Reference
Location in the menu: V1.21.22 (Multi-Purpose Control Application in VACON
This monitoring value shows the final shaft frequency reference for the speed controller.
9.93 (ID 1132) Step Response
Location in the menu: V1.21.23 (Multi-Purpose Control Application in VACON
This monitoring value shows the response for the frequency ramp step.
9.94 (ID 1140) FB Torque Reference
Location in the menu: V1.22.4 (Multi-Purpose Control Application in VACON
This monitoring value shows the fieldbus torque reference.
9.95 (ID 1160) Fieldbus Control Word
Location in the menu: V1.22.1 (Multi-Purpose Control Application in VACON
This monitoring value shows the status of the fieldbus control word that the application uses in bypass mode.
Depending on the fieldbus type or profile, the data that is received from the fieldbus can be modified before it is sent to the applica-
tion.
Table 110: Fieldbus Control Word (ProfiDrive)
Bit Value = 0 (FALSE)
Bit 0 OFF
Bit 1 Emergency stop by coast
Bit 2 Emergency stop by ramp
Bit 3 STOP REQUEST
Bit 4 Force ramp to Zero
Bit 5 Freeze Ramp
Danfoss A/S © 2023.02
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
NXP only)
®
Value = 1 (TRUE)
ON, Reset after Fault or b1 and b2
ON, On normal operation: Keep TRUE
ON, On normal operation: Keep TRUE
RUN REQUEST
Enable Ramp
Enable Ramp
Monitoring Value Descriptions
