VACON® NX All-in-One
Application Guide
• P2.2.13 (Local/Remote Control Application, Multi-Step Speed Control Application)
• P2.2.25 (PID Control Application)
• P2.2.3.6 (Multi-Purpose Control Application, Pump and Fan Control Application)
Use this parameter to filter out disturbances in the analog input signal.
See 10.82 (ID 324) AI1 Signal Filter
10.88 (ID 330) DIN 5 Function
Location in the menu: P2.2.3 (PID Control Application)
Use this parameter to select the function for the digital input signal.
The digital input DIN 5 has 14 possible functions. If it is not needed, set the value of this parameter to 0.
The selections are the same as in parameter ID 319 except:
13 Enable PID reference 2:
•
Contact open: PID controller reference selected with parameter ID 332.
•
Contact closed: PID controller keypad reference 2 selected with parameter R3.5.
10.89 (ID 331) Motor Potentiometer Ramp Time
Location in the menu:
• P2.2.22 (Local/Remote Control Application)
•
P2.2.27 (PID Control Application)
•
P2.2.1.2 (Multi-Purpose Control Application
•
P2.2.1.15 (Pump and Fan Control Application)
Use this parameter to set the rate of change in the motor potentiometer reference when it is increased or decreased.
Motor control ramp times are still active.
10.90 (ID 332) PID Controller Reference Signal
Location in the menu: P2.1.11 (PID Control Application, Pump and Fan Control Application)
Use this parameter to select the source of the PID controller signal.
For selection "Fieldbus ref. (FBProcessDataIN1)" (3 in PID Control Application and 5 in Pump and Fan Control Application), see
10.624 Fieldbus Control Parameters (IDs
10.91 (ID 333) PID Controller Actual Value Selection
Location in the menu:
• P2.2.8 (PID Control Application)
• P2.2.1.8 (Pump and Fan Control Application)
Use this parameter to select the actual value of the PID controller signal.
10.92 (ID 334) Actual Value 1 Selection
Location in the menu:
• P2.2.9 (PID Control Application)
• P2.2.1.9 (Pump and Fan Control Application)
Use this parameter to select the source of the actual value.
For selection "Fieldbus" (5), see
10.93 (ID 335) Actual Value 2 Selection
Location in the menu:
• P2.2.10 (PID Control Application)
• P2.2.1.10 (Pump and Fan Control Application)
Use this parameter to select the source of the actual value.
For selection "Fieldbus" (5), see
198 | Danfoss A/S © 2023.02
Time.
850–859).
10.624 Fieldbus Control Parameters (IDs
10.624 Fieldbus Control Parameters (IDs
850–859).
850–859).
