Use this parameter to set the threshold value for computing the warning 1 high notification threshold. Threshold value range varies
based on warning mode selection. This limit is not used when value is zero.
10.565 (ID 3533) Voltage Warning S1 Delay
Location in the menu: P2.13.3.7.3 (Multi-purpose Control Application)
Use this parameter to define how long time the actual value must be above the warning S1 notification level to trigger the warning
S1. This level is not used when delay is zero.
10.566 (ID 3534) Voltage Warning S2 Mode
Location in the menu: P2.13.3.7.4 (Multi-purpose Control Application)
Use this parameter to select the warning S2 mode which is used for calculating warning S2 notification threshold.
Selection number Selection name
0 Absolute
1 Offset
2 Factor
10.567 (ID 3535) Voltage Warning S2 High
Location in the menu: P2.13.3.7.5 (Multi-purpose Control Application)
Use this parameter to set the threshold value for computing the warning 2 high notification threshold. Threshold value range varies
based on warning mode selection. This limit is not used when value is zero.
10.568 (ID 3536) Voltage Warning S2 Delay
Location in the menu: P2.13.3.7.6 (Multi-purpose Control Application)
Use this parameter to define how long time the actual value must be above the warning S2 notification level to trigger the warning
S2. This level is not used when delay is zero.
10.569 (ID 3537) Voltage Alarm/Fault Mode
Location in the menu: P2.13.3.7.7 (Multi-purpose Control Application)
Use this parameter to select the alarm/fault mode which is used for calculating alarm/fault notification threshold.
Selection number Selection name
0 Absolute
1 Offset
2 Factor
10.570 (ID 3538) Voltage Alarm/Fault High
Location in the menu: P2.13.3.7.8 (Multi-purpose Control Application)
Use this parameter to set the threshold value for computing the alarm/fault high notification threshold. Threshold value range var-
ies based on warning mode selection. This limit is not used when value is zero.
10.571 (ID 3539) Voltage Alarm/Fault Delay
Location in the menu: P2.13.3.7.9 (Multi-purpose Control Application)
Use this parameter to define how long time the actual value must be above the alarm/fault notification level to trigger the alarm/
fault. This level is not used when delay is zero.
10.572 (ID 3540) Condition-based Monitoring Fault Mode
Location in the menu: P2.13.1 (Multi-purpose Control Application)
Use this parameter to set the response of the drive to Exception. This parameter can be set which of stages to be activated.
Danfoss A/S © 2023.02
Description
Absolute value is considered as threshold
Calculates threshold as sum of the computed baseline data and the offset values
Calculates threshold as baseline data factor
Description
Absolute value is considered as threshold
Calculates threshold as sum of the computed baseline data and the offset values
Calculates threshold as baseline data factor
