2.4.3 Keypad Control (Control Panel: Menu M3)

The parameters for the selection of control place and direction on the keypad are listed in
the User Manual of the product.
Table 4: Keypad Control Parameters, M3
Index Parameter
P3.1 Control place
P3.2 Keypad reference
P3.3 Direction (on keypad)
R3.4 Stop button

2.4.4 System Menu (Control Panel: Menu M6)

For more information related to the general use of the AC drive, such as selecting application and language, customized parameter
sets, or hardware and software, see the User Manual of the product.

2.4.5 Expander Boards (Control Panel: Menu M7)

The M7 menu shows the expander and option boards attached to the control board and board-related information. For more infor-
mation, see the User Manual of the product.
Danfoss A/S © 2023.02
Min Max Unit Default
-
1 3 1
P2.1 P2.2 Hz 0.00
-
0 1 0
-
0 1 1
Table 4. See the Keypad control menu in
ID Description
125 1 = I/0 terminal
2 = Keypad
3 = Fieldbus
- -
123 0 = Forward
1 = Reverse
114 0 = Limited function of Stop button
1 = Stop button always enabled
AB296635287482en-000301 / DPD00903 | 15
