VACON® NX All-in-One
Application Guide
Index Parameter
P2.2.7
(1)
Fieldbus control refer-
ence selection
P2.2.8
(1)
Actual value selection
P2.2.9
(1)
Actual value 1 selection
P2.2.10
(1)
Actual value 2 input
P2.2.11 Actual value 1 mini-
mum scale
P2.2.12 AI2 custom setting
maximum
P2.2.13 AI2 signal inversion
P2.2.14 AI2 signal filter time
P2.2.15
(2)
AI1 signal selection
P2.2.16
(3)
AI1 signal range
66 | Danfoss A/S © 2023.02
Min Max Unit Default
-
0 7 5
-
0 7 0
-
0 10 2
-
0 10 0
–1600.0 1600.0 % 0.0
–1600.0 1600.0 % 100.0
–1600.0 1600.0 % 0.0
–1600.0 1600.0 % 100.0
-
0.1 E.10 A.1
-
0 2 0
PID Control Application
ID Description
6 = Motor potentiometer
122
7 = PID controller
333 0 = Actual value 1
1 = Actual 1 + Actual 2
2 = Actual 1 – Actual 2
3 = Actual 1 x Actual 2
4 = Min(Actual 1, Actual 2)
5 = Max(Actual 1, Actual 2)
6 = Mean (Actual1, Actual2
7 = Sqrt (Actual 1) + Sqrt (Actual 2)
334 0 = Not used
1 = AI1 signal (cboard)
2 = AI2 signal (cboard)
3 = AI3
4 = AI4
5 = Fieldbus ProcessDataIN2
6 = Motor torque
7 = Motor speed
8 = Motor current
9 = Motor power
10 = Encoder frequency
335 0 = Not used
1 = AI1 signal
2 = AI2 signal
3 = AI3
4 = AI4
5 = Fieldbus ProcessDataIN3
6 = Motor torque
7 = Motor speed
8 = Motor current
9 = Motor power
10 = Encoder Frequency
336 0 = No minimum scaling
337 100 = No maximum scaling
338 0 = No minimum scaling
339 100 = No maximum scaling
-
377
320 0 = 0–10 V (0–20 mA)
1 = 2–10 V (4–20 mA)
2 = Custom range
AB296635287482en-000301 / DPD00903
