Danfoss VACON NX All-in-One Application Manual page 68

VACON® NX All-in-One
Application Guide
Index Parameter
P2.2.35 Reference scaling mini-
mum value, place B
P2.2.36 Reference scaling maxi-
mum value, place B
P2.2.37 Easy changeover
P2.2.38
(2)
AI3 signal selection
P2.2.39 AI3 signal range
P2.2.40 AI3 inversion
P2.2.41 AI3 filter time
P2.2.42
(2)
AI4 signal selection
P2.2.43 AI4 signal range
P2.2.44 AI4 inversion
P2.2.45 AI4 filter time
P2.2.46 Actual value special dis-
play minimum
P2.2.47 Actual value special dis-
play maximum
P2.2.48 Actual value special dis-
play decimals
P2.2.49 Actual value special dis-
play unit
Parameter value can only be changed after the AC drive has been stopped.
1
2 Use the Terminal to Function method (TTF) with these parameters, see
Remember to place jumpers of block X2 according to the selection (0, 1 or 2). See the User Manual of the product.
3
CP = control place
cc = closing contact
oc = opening contact
68 | Danfoss A/S © 2023.02
Min Max Unit Default
0.00 320.0 Hz 0.00
0.00 320.0 Hz 0.00
-
0 1 0
-
0.1 E.10 0.1
-
0 1 1
-
0 1 0
0.00 10.00 s 0.10
-
0.1 E.10 0.1
-
0 1 1
-
0 1 0
0.00 10.00 s 0.10
-
0 30000 0
-
0 30000 100
-
0 4 1
-
0 29 4
10.626 "Terminal to Function" (TTF) Programming
PID Control Application
ID Description
-
344
-
345
366 0 = Keep reference
1 = Copy actual reference
-
141
143 0 = Signal range 0–10 V
1 = Signal range 2–10 V
151 0 = Not inverted
1 = Inverted
142 0 = No filtering
-
152
154 0 = Signal range 0–10 V
1 = Signal range 2–10 V
162 0 = Not inverted
1 = Inverted
153 0 = No filtering
-
1033
-
1034
-
1035
1036 See 10.440 (ID 1036) Actual Value Special Dis-
play Unit.
AB296635287482en-000301 / DPD00903
Principle.
