VACON® NX All-in-One
Application Guide
Table 2: Monitoring Values
Index Monitoring value
V1.1 Output frequency
V1.2 Frequency reference
V1.3 Motor speed
V1.4 Motor current
V1.5 Motor torque
V1.6 Motor shaft power
V1.7 Motor voltage
V1.8 DC-link voltage
V1.9 Unit temperature
V1.10 Motor temperature
V1.11 Analog input 1
V1.12 Analog input 2
V1.13 DIN 1, 2, 3
V1.14 DIN 4, 5, 6
V1.15 DO1, RO1, RO2
V1.16 Analog I
out
V1.17 Multimonitoring items
2.4.2 Basic Parameters (Control Panel: Menu M2 -> G2.1)
Table 3: Basic Parameters G2.1
Index Parameter
P2.1 Min frequency
P2.2 Max frequency
P2.3 Acceleration time 1
P2.4 Deceleration time 1
P2.5 Current limit
P2.6 Nominal voltage of the motor
P2.7 Nominal frequency of the mo-
tor
P2.8 Nominal speed of the motor
Danfoss A/S © 2023.02
Unit
Hz
Hz
RPM
A
%
%
V
V
°C
%
V/mA
V/mA
-
-
-
mA
-
Min Max Unit Default
0.00 P2.2 Hz 0.00
P2.1 320.00 Hz 50.00
0.1 3000.0 s 3.0
0.1 3000.0 s 3.0
0.1 x I 2 x I A I
H H L
180 690 V NX2: 230 V
NX5: 400 V
NX6: 690 V
8.00 320.00 Hz 50.00
24 20 000 RPM 1440
Form ID Description
#.## 1 -
#.## 25 -
# 2 -
Varies 3 -
#.# 4 -
#.# 5 -
#.# 6 -
# 7 -
# 8 -
#.# 9 -
#.## 13 -
#.## 14 -
- 15 -
- 16 -
- 17 -
#.## 26 -
- - -
ID Description
-
101
-
102
-
103
-
104
-
107
-
110
-
111
-
112
AB296635287482en-000301 / DPD00903 | 13
Basic Application
