3.4.6 Prohibit Frequency Parameters (Control Panel: Menu M2 -> G2.5)
Table 10: Prohibit Frequency Parameters, G2.5
Index Parameter
P2.5.1 Prohibit frequency range 1 low limit
P2.5.2 Prohibit frequency range 1 high limit
P2.5.3 Prohibit acc./dec. ramp
3.4.7 Motor Control Parameters (Control Panel: Menu M2 -> G2.6)
Table 11: Motor Control Parameters, G2.6
Index Parameter
P2.6.1
(1)
Motor control mode
P2.6.2
(1)
U/f optimisation
P2.6.3
(1)
U/f ratio selection
P2.6.4
(1)
Field weakening point
P2.6.5
(1)
Voltage at field weakening point
P2.6.6
(1)
U/f curve midpoint frequency
P2.6.7
(1)
U/f curve midpoint voltage
P2.6.8
(1)
Output voltage at zero frequency
P2.6.9 Switching frequency
Overvoltage controller
P2.6.10
P2.6.11 Undervoltage controller
P2.6.12 Load drooping
24 | Danfoss A/S © 2023.02
Min Max
0.00 320.00
0.00 320.00
0.1 10.0
Min Max Unit Default
-
0 1/4 0
-
0 1 0
-
0 3 0
8.00 320.00 Hz 50.00
10.00 200.00 % 100.00
0.00 P2.6.4 Hz 50.00
0.00 100.00 % 100.00
0.00 40.00 % Varies
1.0 Varies kHz Varies
-
0 2 1
-
0 2 2
0.00 100.00 % 0.00
Standard Application
Unit Default ID
Hz 0.00 509
Hz 0.00 510
x 0.1 518
ID Description
600 0 = Frequency control
1 = Speed control
VACON NXP:
®
2 = Open loop torque control
3 = Closed loop speed ctrl
4 = Closed loop torque control
109 0 = Not used
1 = Automatic torque boost
108 0 = Linear
1 = Squared
2 = Programmable
3 = Linear with flux optim.
-
602
-
603
-
604
-
605
-
606
-
601
607 0 = Not used
1 = Used (no ramping)
2 = Used (ramping)
608 0 = Not used
1 = Used
2 = Used (ramping to zero)
-
620
