VACON® NX All-in-One
Application Guide
Index Parameter
P2.2.4.4
AI3 custom minimum setting
P2.2.4.5 AI3 custom maximum setting
P2.2.4.6 AI3 signal inversion
Use the Terminal to Function method (TTF) with these parameters, see
1
Remember to place jumpers of block X2 according to the selection (0, 1, 2 or 3). See the User Manual of the product.
2
Table 60: Analog Input 4 (Control Panel: Menu M2 -> G2.2.5)
Index Parameter
P2.2.5.1
(1)
AI4 signal selection
P2.2.5.2
AI4 filter time
P2.2.5.3
(2)
AI4 signal range
P2.2.5.4
AI4 custom minimum setting
P2.2.5.5 AI4 custom maximum setting
P2.2.5.6 AI4 signal inversion
Use the Terminal to Function method (TTF) with these parameters, see
1
2 Remember to place jumpers of block X2 according to the selection (0, 1, 2 or 3). See the User Manual of the product.
Table 61: Free Analog Input, Signal Selection (Control Panel: Menu M2 -> G2.2.6
Index Parameter
P2.2.6.1
Scaling of current limit
P2.2.6.2
Scaling of DCbraking current
P2.2.6.3
Scaling of acc./ dec. times
P2.2.6.4
Scaling of torque supervision limit
P2.2.6.5 Scaling of torque limit
VACON NXP drives only
®
Danfoss A/S © 2023.02
Min Max Unit
-160.00 160.00 %
-160.00 160.00 %
-
0 1
10.626 "Terminal to Function" (TTF) Programming
Min Max Unit
-
0.1 E.10
0.00 320.00 s
-
0 3
-160.00 160.00 %
-160.00 160.00 %
-
0 1
10.626 "Terminal to Function" (TTF) Programming
Min Max Unit Default
-
0 5 0
-
0 5 0
-
0 5 0
-
0 5 0
-
0 5 0
Multi-purpose Control Application
Default ID Description
3 = Custom range
-
0.00 144
-
100.00 145
0 151 0 = Not inverted
1 = Inverted
Principle)
Default ID Description
-
0.1 152
0.00 153 0 = No filtering
1 154 0 = 0–10 V (0-20mA)
1 = 2–10 V (4–20 mA)
2 = -10V...+10 V
3 = Custom range
-
20.00 155
-
100.00 156
0 162 0 = Not inverted
1 = Inverted
Principle)
ID Description
399 0 = Not used
1= AI1
400
2 = AI2
3 = AI3
401
4 = AI4
5 = FB Limit Scaling See group G2.9
402
485
