VACON® NX All-in-One
Application Guide
Table 122: Current Scaling in Different Size of Units
Voltage (V AC)
208–240
208–240
380–500
380–500
380–500
525–690
525–690
10.624.3 Process Data in (Master -> Slave)
ControlWord, Reference, and Process Data are used in All in One applications as follows:
Table 123: Basic, Standard, Local/Remote, Multi-Step Applications
Data
Reference
ControlWord
PD1 – PD8
The settings in Table 124 are factory defaults. See also parameter group G2.9.
Table 124: Multi-Purpose Control Application
Data
Reference
ControlWord
Process Data IN1
Process Data IN2
Process Data IN3
PD4 – PD8
Table 125: PID Control and Pump and Fan Control Applications
Data
Reference
ControlWord
Process Data IN1
310 | Danfoss A/S © 2023.02
Size
NX_2 0001–0011
NX_2 0012–0420
NX_5 0003–0007
NX_5 0009–0300
NX_5 0385 –
NX_6 0004–0013
NX_6 0018 –
Value
Speed reference
Start/Stop command
Fault reset command
Not used
Value
Speed reference
Start/Stop command
Fault reset command
Torque reference
Free analog input
Adjust input
Not used
Value
Speed reference
Start/Stop command
Fault reset command
Reference for PID controller
Parameter Descriptions
Scale
100 – 0.01 A
10 – 0.1 A
100 – 0.01 A
10 – 0.1 A
1–1 A
100 – 0.01 A
10 – 0.1 A
Unit Scale
% 0.01%
- -
- -
Unit Scale
% 0.01%
- -
% 0.01%
% 0.01%
% 0.01%
- -
Unit Scale
% 0.01%
- -
% 0.01%
AB296635287482en-000301 / DPD00903
