VACON® NX All-in-One
Application Guide
10.606 (ID 3576) Load Warning S2 High
Location in the menu: P2.13.5.2.5 (Multi-purpose Control Application)
Use this parameter to set the threshold value for computing the warning 2 high notification threshold. Threshold value range varies
based on warning mode selection. This limit is not used when value is zero.
10.607 (ID 3577) Load Warning S2 Delay
Location in the menu: P2.13.5.2.6 (Multi-purpose Control Application)
Use this parameter to define how long time the actual value must be above the warning S2 notification level to trigger the warning
S2. This level is not used when delay is zero.
10.608 (ID 3578) Load Alarm/Fault Mode
Location in the menu: P2.13.5.2.7 (Multi-purpose Control Application)
Use this parameter to select the alarm/fault mode which is used for calculating alarm/fault notification threshold.
Selection number Selection name
0 Absolute
1 Offset
2 Factor
10.609 (ID 3579) Load Alarm/Fault High
Location in the menu: P2.13.5.2.8 (Multi-purpose Control Application)
Use this parameter to set the threshold value for computing the alarm/fault high notification threshold. Threshold value range var-
ies based on warning mode selection. This limit is not used when value is zero.
10.610 (ID 3580) Load Alarm/Fault Delay
Location in the menu: P2.13.5.2.9 (Multi-purpose Control Application)
Use this parameter to define how long time the actual value must be above the alarm/fault notification level to trigger the alarm/
fault. This level is not used when delay is zero.
10.611 (ID 3581) Load Warning S1 Counter
Location in the menu: P2.13.5.3.1 (Multi-purpose Control Application)
Use this parameter to set warning S1 counter value.
10.612 (ID 3582) Load Warning S2 Counter
Location in the menu: P2.13.5.3.2 (Multi-purpose Control Application)
Use this parameter to set warning S2 counter value.
10.613 (ID 3583) Load Alarm/Fault Counter
Location in the menu: P2.13.5.3.3 (Multi-purpose Control Application)
Use this parameter to set alarm/fault counter value.
10.614 (ID 3584) Load Warning S1 Low
Location in the menu: P2.13.5.2.10 (Multi-purpose Control Application)
Use this parameter to set the threshold value for computing the warning 1 low notification threshold. Threshold value range varies
based on warning mode selection. This limit is not used when value is zero.
10.615 (ID 3585) Load Warning S2 Low
Location in the menu: P2.13.5.2.11 (Multi-purpose Control Application)
Use this parameter to set the threshold value for computing the warning 2 low notification threshold. Threshold value range varies
based on warning mode selection. This limit is not used when value is zero.
304 | Danfoss A/S © 2023.02
Description
Absolute value is considered as threshold
Calculates threshold as sum of the computed baseline data and the offset values
Calculates threshold as baseline data factor
Parameter Descriptions
