VACON® NX All-in-One
Application Guide
Index Parameter
P2.2.22 Motor potentiometer ramp time
P2.2.23 Motor potentiometer frequency
reference memory reset
P2.2.24 Start pulse memory
Parameter value can only be changed after the AC drive has been stopped.
1
Use the Terminal to Function method (TTF) with these parameters, see
2
3 Remember to place jumpers of block X2 according to the selection (0, 1 or 2). See the User Manual of the product.
4.4.4 Output Signals (Control Panel: Menu M2 -> G2.3)
Table 18: Output Signals, G2.3
Index Parameter
P2.3.1
(1)
Analog output 1 signal selec-
tion
P2.3.2 Analog output function
P2.3.3 Analog output filter time
P2.3.4 Analog output inversion
P2.3.5 Analog output minimum
P2.3.6 Analog output scale
P2.3.7 Digital output 1 function
Danfoss A/S © 2023.02
Min Max Unit
0.1 2000.0 Hz/s
-
0 2
-
0 1
10.626 "Terminal to Function" (TTF) Programming
Min Max Unit Default
-
0.1 E.10 A11
-
0 8 1
0.00 10.00 s 1.00
-
0 1 0
-
0 1 0
10 1000 % 100
-
0 22 1
Local/Remote Control Application
Default ID Description
-
10.0 331
1 367 0 = No reset
1 = Reset if stopped or powered down
2 = Reset if powered down
0 498 0 = Run state not copied
1 = Run state copied
ID Description
-
464
307 0 = Not used (20 mA/10V)
1 = Output freq. (0–f
2 = Freq. reference (0–f
3 = Motor speed (0–Motor nominal speed)
4 = Motor current (0–I
5 = Motor torque (0–T
6 = Motor power (0–P
7 = Motor voltage (0–U
8 = DC-link volt (0–1000 V)
308 0 = No filtering
309 0 = Not inverted
1 = Inverted
310 0 = 0 mA (0 V)
1 = 4 mA (2 V)
-
311
312 0 = Not used
1 = Ready
2 = Run
3 = Fault
4 = Fault inverted
5 = AC drive overheat warning
6 = Ext. fault or warning
7 = Ref. fault or warning
8 = Warning
AB296635287482en-000301 / DPD00903 | 37
Principle.
)
max
)
max
)
nMotor
)
nMotor
)
nMotor
)
nMotor
