7.4.15 Condition-based Monitoring (Control Panel: Menu M2 -> G.13)
For more detailed information on the commissioning and use of Condition-based Monitoring, refer to the VACON
Monitoring Application Guide.
Table 88: Condition-based Monitoring Parameters, G2.13
Index Name
P2.13.1.1 Baseline Type
P2.13.1.2 Baseline Min Freq
P2.13.1.3 Baseline Max Freq
P2.13.1.4 Baseline Duration
P2.13.1.5 Modified Array
P2.13.1.6 Modified Point
P2.13.1.7 Modified Value
P2.13.1.8 Modified Activation
P2.13.1.9 Baseline Data Selector
Danfoss A/S © 2023.02
Min Max Unit De-
fault
-
0 3 0
-
0 1 0
Min
0
0.00
0.00
1
0
0
-300.00
0
0
ID Description
3 = Stop by ramping, deceleration ramp according to ramp
configured to the safety option board
543
544 0 = No action
1 = Prohibit speed reference on unintended direction
Max Unit Default
3 - 0
320.00 Hz 0
320.00 Hz 50.00
300 000 min 2
16 - 0
9 - 0
320.00 Hz or % 0
1 - 0
20 - 0
Multi-purpose Control Application
Condition-based
®
ID Description
3501
0 = No Action
1 = Baseline Run
2 = Online Baseline
3 = Baseline Finished
3502 -
3503 -
3504 -
3506
0 = Freq Points
1 = Current Max Steady
2 = Current Min Steady
3 = Current Mean Steady
4 = Current Std Steady
5 = Voltage Max Steady
6 = Voltage Min Steady
7 = Voltage Mean Steady
8 = Voltage Std Steady
9 = Vibration Max Ramp
10= Vibration Min Ramp
11 = Vibration Mean Ramp
12 = Vibration Std Ramp
13 = Load Max Steady
14 = Load Min Steady
15 = Load Mean Steady
16 = Load Std Steady
3507 -
3508 -
3505 -
3509
0 = Freq Points
1 = Current Max Steady
2 = Current Min Steady
3 = Current Mean Steady
