VACON® NX All-in-One
Application Guide
Index Parameter
P2.8.6 Number of tries after overcurrent trip
P2.8.7 Number of tries after 4 mA reference trip
P2.8.8 Number of tries after motor temperature fault trip
P2.8.9 Number of tries after external fault trip
P2.8.10 Number of tries after underload fault trip

6.4.10 Keypad Control (Control Panel: Menu M3)

The parameters for the selection of control place and direction on the keypad are listed below. See the Keypad control menu in the
User Manual of the product.
Table 44: Keypad Control Parameters, M3
Index Parameter
P3.1 Control place
P3.2 Keypad reference
P3.3 Direction (on keypad)
P3.4 PID reference
P3.5 PID reference 2
R3.4 Stop button

6.4.11 System Menu (Control Panel: Menu M6)

For more information related to the general use of the AC drive, such as selecting application and language, customized parameter
sets, or hardware and software, see the User Manual of the product.

6.4.12 Expander Boards (Control Panel: Menu M7)

The M7 menu shows the expander and option boards attached to the control board and board-related information. For more infor-
mation, see the User Manual of the product.
76 | Danfoss A/S © 2023.02
Min
0
0
0
0
0
Min Max Unit
-
1 3
P2.1.1 P2.1.2 Hz
-
0 1
0.00 100.00 %
0.00 100.00 %
-
0 1
Max Unit Default
-
3 0
-
10 0
-
10 0
-
10 0
-
10 0
Default ID Description
1 125 1 = I/0 terminal
2 = Keypad
3 = Fieldbus
- -
0.00
0 123 0 = Forward
1 = Reverse
-
0.00 167
-
0.00 168
1 114 0 = Limited function of Stop button
1 = Stop button always enabled
AB296635287482en-000301 / DPD00903
PID Control Application
ID Description
-
722
-
723
-
726
-
725
-
738
