VACON® NX All-in-One
Application Guide
FWD
f
out
REV
DIN4
DIN5
Illustration 55: Start Forward/Start Reverse
1.
The first selected direction has the highest priority.
2.
When the DIN 4 contact opens the direction of rota-
tion starts the change.
FWD
f
out
REV
DIN4
DIN5
Illustration 56: Start, Stop, Reverse
A
Stop function (ID 506) = coasting.
208 | Danfoss A/S © 2023.02
A
A
1
2
3.
Start pulse/ Stop pulse.
A
Stop function (ID 506) = coasting.
AB296635287482en-000301 / DPD00903
Parameter Descriptions
t
3
t
