VACON® NX All-in-One
Application Guide
10.121 (ID 363) Start/Stop Logic Selection, Place B
Location in the menu: P2.2.15 (Local/Remote Control Application)
Use this parameter to control the start and stop of the drive with the digital signals.
Selec- DIN 3
tion
0 -
(1)
1 -
(2)
2 -
3 Can be pro-
(3)(4)
grammed for
reverse com-
mand.
4 -
(5)
5 -
(5)
6 -
(5)
See Illustration 55.
1
See Illustration 56.
2
See Illustration 57.
3
3-wire connection (pulse control)
4
The selections 4–6 are used to exclude the possibility of an unintentional start when, for example, power is connected, reconnected after a power
5
failure, after a fault reset, after Run Enable (Run Enable = False) stops the drive or when the control place is changed. The Start/Stop contact must be
opened before the motor can be started.
The selections including the text 'Rising edge required to start' are used to exclude the possibility of an unintentional start when, for example,
6
power is connected, reconnected after a power failure, after a fault reset, after the drive is stopped by Run Enable (Run Enable = False) or when the
control place is changed from I/O control. The Start/Stop contact must be opened before the motor can be started.
Danfoss A/S © 2023.02
DIN 4
closed contact = start forward
closed contact = start
open contact = stop
closed contact = start
open contact = stop
closed contact= start pulse
closed contact = start forward (Rising edge re-
quired to start)
(6)
closed contact = start reverse (Rising edge re-
quired to start)
(6)
open contact = stop
closed contact = start reverse (Rising edge re-
quired to start)
(6)
open contact = stop
Parameter Descriptions
DIN 5
closed contact = start reverse
closed contact = reverse
open contact = forward
closed contact = start enabled
open contact = start disabled and drive stopped if
running
open contact = stop pulse
closed contact = start reverse (Rising edge required
to start)
(6)
closed contact = reverse
open contact = forward
closed contact = start enabled
open contact = start disabled and drive stopped if
running
