VACON® NX All-in-One
Application Guide
See 10.261 (ID 550) Fieldbus Data In Selection
10.268 (ID 557) Fieldbus Data In Selection 16
Location in the menu: P2.9.34 (Multi-purpose Control Application, VACON
Use this parameter to select a parameter or monitoring value to be controlled from the fieldbus.
See 10.261 (ID 550) Fieldbus Data In Selection
10.269 (ID 558) Fieldbus Data Out Selection 9
Location in the menu: P2.9.11 (Multi-purpose Control Application, VACON
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
These parameters are visible only if the option board installed to AC drive supports 16 Process data items.
See also Table 46 for more monitoring values.
10.270 (ID 559) Fieldbus Data Out Selection 10
Location in the menu: P2.9.12 (Multi-purpose Control Application, VACON
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
See 10.269 (ID 558) Fieldbus Data Out Selection
10.271 (ID 560) Fieldbus Data Out Selection 11
Location in the menu: P2.9.13 (Multi-purpose Control Application, VACON
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
See 10.269 (ID 558) Fieldbus Data Out Selection
10.272 (ID 561) Fieldbus Data Out Selection 12
Location in the menu: P2.9.14 (Multi-purpose Control Application, VACON
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
See 10.269 (ID 558) Fieldbus Data Out Selection
10.273 (ID 562) Fieldbus Data Out Selection 13
Location in the menu: P2.9.15 (Multi-purpose Control Application, VACON
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
See 10.269 (ID 558) Fieldbus Data Out Selection
10.274 (ID 563) Fieldbus Data Out Selection 14
Location in the menu: P2.9.16 (Multi-purpose Control Application, VACON
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
See 10.269 (ID 558) Fieldbus Data Out Selection
10.275 (ID 564) Fieldbus Data Out Selection 15
Location in the menu: P2.9.17 (Multi-purpose Control Application, VACON
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
See 10.269 (ID 558) Fieldbus Data Out Selection
10.276 (ID 565) Fieldbus Data Out Selection 16
Location in the menu: P2.9.18 (Multi-purpose Control Application, VACON
Use this parameter to select the data that is sent to the fieldbus with the ID number of the parameter or monitor value.
See 10.269 (ID 558) Fieldbus Data Out Selection
10.277 (ID 600) Motor Control Mode
Location in the menu: P2.6.1 (Standard Application, Local/Remote Control Application, Multi-step Speed Control Application, PID
Control Application, Multi-purpose Control Application, Pump and Fan Control Application)
Use this parameter to set the AC drive control mode.
Danfoss A/S © 2023.02
9.
®
9.
®
®
9.
®
9.
®
9.
®
9.
®
9.
®
9.
®
9.
NXP)
NXP)
NXP)
NXP)
NXP)
NXP)
NXP)
NXP)
NXP)
AB296635287482en-000301 / DPD00903 | 239
Parameter Descriptions
