VACON® NX All-in-One
Application Guide
10.73 (ID 313) Relay Output 1 Function
Location in the menu: P2.3.8 (Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application, PID
Control Application)
Use this parameter to select the function for the relay output signal.
See 10.72 (ID 312) Digital Output
10.74 (ID 314) Relay Output 2 Function
Location in the menu: P2.3.9 (Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application, PID
Control Application)
Use this parameter to select the function for the relay output signal.
See 10.72 (ID 312) Digital Output
10.75 (ID 315) Output Frequency Limit Supervision Function
Location in the menu:
• P2.3.10 (Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application, PID Control Applica-
tion)
• P2.3.2.1 (Pump and Fan Control Application)
• P2.3.4.1 (Multi-Purpose Control Application)
Use this parameter to select the limit supervision function for the output frequency.
If the output frequency goes under/over the set limit (ID 316), this function generates a message via digital output depending on:
•
the settings of parameters ID 312 to ID 314 (Standard Application, Local/Remote Control Application, Multi-Step Speed Control
Application) or
• to which output the supervision signal 1 (ID 447) is connected (Multi-Purpose Control Application, Pump and Fan Control Appli-
cation).
Selection "Brake-on control" is available only for Multi-Purpose Control Application. See
tional Limits (IDs 315, 316, 346–349, 352,
Brake control uses different output functions. See
Inverted.
10.76 (ID 316) Output Frequency Limit Supervision Value
Location in the menu:
• P2.3.11 (Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application, PID Control Applica-
tion)
• P2.3.2.2 (Pump and Fan Control Application)
•
P2.3.4.2 (Multi-Purpose Control Application)
Use this parameter to set the limit supervision value for the output frequency when activating the limit supervision function.
Selects the frequency value supervised by parameter ID 315.
192 | Danfoss A/S © 2023.02
Function.
Function.
353).
10.189 (ID 445) External Brake Control
Parameter Descriptions
10.620 External Brake Control with Addi-
and 10.190 (ID 446) External Brake Control,
AB296635287482en-000301 / DPD00903
