VACON® NX All-in-One
Application Guide
Table 116: Selections for Parameter ID 301
Selection Selection name
number
0 Not used
1
External fault
2
External fault
3
Run enable
Basic Application
4
Run enable
Standard Application, Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application, PID
Control Application
4
Acc./Dec time se-
lect.
5
Closing contact
6
Closing contact
7
Closing contact
8
Reverse
Local/Remote Control Application, Multi-Step Speed Control Application, PID Control Application
9 Jogging sp.
10 Fault reset
11 Acc./dec. operation
prohibited
12 DC-braking com-
mand
Local/Remote Control Application, PID Control Application
184 | Danfoss A/S © 2023.02
Description
-
Closing contact: Fault is shown and
responded to according to ID 701.
Opening contact: Fault is shown and
responded to according to ID 701
when the input is not active.
Contact open: Motor start disabled
and the motor is stopped READY sig-
nal is set to FALSE
Contact closed: Motor start enabled
Contact open: Motor start enabled
Contact closed: Motor start disabled
and the motor is stopped
Contact open: Acceleration/decelera-
tion time 1 selected
Contact closed: Acceleration/deceler-
ation time 2 selected
Force control place to I/O terminal
Force control place to keypad
Force control place to fieldbus
Contact open: Forward
Contact closed: Reverse
Contact closed: Jogging speed selec-
ted for frequency reference
Contact closed: Resets all faults
Contact closed: Stops acceleration or
deceleration until the contact is
opened
Contact closed: In Stop mode, the DC-
braking operates until the contact is
opened, see Figure 30 and parame-
ters ID 507 and ID 1080
Parameter Descriptions
Notes
-
-
-
-
-
When the control place is forced to change, the
values of Start/Stop, Direction, and Reference
valid in the respective control place are used
(reference according to parameters ID 117, ID
121, and ID 122).
The value of parameter ID 125 Keypad Control
Place does not change. When DIN 3 opens, the
control place is selected according to parame-
ter 3.1.
Can be used for reversing if parameter ID300
value is set to either 2, 3, or 6.
-
-
-
-
