B Maximum value of signal selected with ID 307
Maximum output signal = Minimum set value
Minimum output signal = Maximum set value
See 10.71 (ID 311) Analog Output 1
10.70 (ID 310) Analog Output 1 Minimum
Location in the menu:
•
P2.3.5 (Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application, PID Control Application)
•
P2.3.5.5 (Multi-Purpose Control Application)
• P2.3.3.5 (Pump and Fan Control Application)
Use this parameter to set the minimum value of the analog output 1 signal.
The parameter defines the signal minimum to either 0 mA or 4 mA (living zero). Note the difference in analog output scaling in
parameter ID 311.
10.71 (ID 311) Analog Output 1 Scale
Location in the menu:
• P2.3.6 (Standard Application, Local/Remote Control Application, Multi-Step Speed Control Application, PID Control Application)
•
P2.3.5.6 (Multi-Purpose Control Application)
•
P2.3.3.6 (Pump and Fan Control Application)
Use this parameter to set the scaling factor for the analog 1 output.
Signal
Output frequency
Freq. Reference
Motor speed
Output current
Motor torque
Motor power
Motor voltage
DC-link voltage
PI-ref. value
PI act. value 1
PI act. value 2
PI error value
PI output
Danfoss A/S © 2023.02
Scale.
Max. value of the signal
Max frequency (parameter ID102)
Max frequency (parameter ID102)
Motor nom. speed 1xn
Motor nom. current 1xI
Motor nom. torque 1xT
Motor nom. power 1xP
100% x U
nmotor
1000 V
100% x ref. value maximum
100% x actual value maximum
100% x actual value maximum
100% x error value maximum
100% x output maximum
mMotor
nMotor
nMotor
nMotor
