Index Parameter
P2.3.3.16
(1)
Output frequency limit 1 supervision
P2.3.3.17
(1)
Output frequency limit 2 supervision
P2.3.3.18
(1)
Reference limit supervision
P2.3.3.19
(1)
Temperature limit supervision
P2.3.3.20
(1)
Torque limit supervision
P2.3.3.21
(1)
Thermistor fault or warning
P2.3.3.22
(1)
Analog input supervision limit
P2.3.3.23
(1)
Motor regulator activation
P2.3.3.24
(1)
Fieldbus DIN 1
P2.3.3.25
(1)
Fieldbus DIN 2
P2.3.3.26
(1)
Fieldbus DIN 3
P2.3.3.27
(1)
Fieldbus DIN 4
P2.3.3.28
(1)
Fieldbus DIN 5
VACON NXP drives only
®
P2.3.3.29
(1)
DC ready pulse
P2.3.3.30
(1)
Safe Disable Active
Use the Terminal to Function method (TTF) with these parameters, see
1
Table 66: Limit Settings (Control Panel: Menu M2 -> G2.3.4)
Index Parameter
P2.3.4.1
Output frequency limit 1 supervision
P2.3.4.2
Output frequency limit 1; Supervised value
P2.3.4.3
Output frequency limit 2 supervision
100 | Danfoss A/S © 2023.02
Min Default ID Description
0.1 0.1 447 See
sion Function
0.1 0.1 448 See
pervision
0.1 0.1 449 See
Function.
0.1 0.1 450 See
ture Limit
0.1 0.1 451 See
tion.
-
0.1 0.1 452
0.1 0.1 453 See
-
0.1 0.1 454
-
0.1 0.1 455
-
0.1 0.1 456
-
0.1 0.1 457
-
0.1 0.1 169
-
0.1 0.1 170
-
0.1 0.1 1218
-
0.1 0.1 756
10.626 "Terminal to Function" (TTF) Programming
Min Max Unit
-
0 3
0.00 320.00 Hz
-
0 4
Multi-purpose Control Application
10.75 (ID 315) Output Frequency Limit Supervi-
10.104 (ID 346) Output Frequency Limit 2 Su-
Function.
10.108 (ID 350) Reference Limit, Supervision
10.112 (ID 354) Frequency Converter Tempera-
Supervision.
10.106 (ID 348) Torque Limit, Supervision Func-
10.114 (ID 356) Analog Supervision
Principle)
Default ID Description
0 315 0 = No supervision
1 = Low limit supervision
2 = High limit supervision
3 = Brake-on control
-
0.00 316
0 346 0 = No supervision
1 = Low limit supervision
2 = High limit supervision
AB296635287482en-000301 / DPD00903
