P2.9 Nominal current of the motor
P2.10 Motor cos phi
P2.11 Start function
P2.12 Stop function
P2.13 U/f optimization
P2.14 I/O reference
P2.15 Analog input 2, reference off-
set
P2.16 Analog output function
P2.17 DIN 3 function
P2.18 Preset speed 1
P2.19 Preset speed 2
P2.20 Automatic restart
14 | Danfoss A/S © 2023.02
Min Max Unit Default
0.1 x I 2 X I A I
H H H
-
0.30 1.00 0.85
-
0 2 0
-
0 3 0
-
0 1 0
-
0 3 0
-
0 1 1
-
0 8 1
-
0 7 1
0.00 P2.2 Hz 0.00
0.00 P2.2 Hz 50.00
-
0 1 0
ID Description
-
113
-
120
505 0 = Ramp
1 = Flying start
2 = Conditional flying start
506 0 = Coasting
1 = Ramp
2 = Ramp + Run enable coast Ramp
3 = Coast + Run enable ramp
109 0 = Not used
1 = Automatic torque boost
117 0 = AI1
1 = AI2
2 = Keypad
3 = Fieldbus
302 0 = 0–20 mA
1 = 4–20 mA
307 0 = Not used
1 = Output freq. (0- f
max
2 = Freq. reference (0-f
3 = Motor speed (0-Motor nominal speed)
4 = Output current (0-InMotor)
5 = Motor torque (0-TnMotor)
6 = Motor power (0-PnMotor)
7 = Motor voltage (0-UnMotor)
8 = DC-link volt (0-1000V)
301 0 = Not used
1 = Ext. fault, closing cont.
2 = Ext. fault, opening cont.
3 = Run enable, cc
4 = Run enable, oc
5 = Force cp. to I/O
6 = Force cp. to keypad
7 = Force cp. to fieldbus
-
105
-
106
731 0 = Disabled
2 = Enabled
