Input Signals (Control Panel: Menu M2 -> G2.2) - Danfoss VACON NX All-in-One Application Manual

VACON® NX All-in-One
Application Guide
Index Parameter
P2.1.17 Wake up level
P2.1.18 Wake up function
P2.1.19 Jogging speed reference
Parameter value can only be changed after the AC drive has been stopped.
1
6.4.3 Input Signals (Control Panel: Menu M2 -> G2.2)
Table 37: Input Signals, G2.2
Index Parameter
P2.2.1
(1)
DIN 2 function
P2.2.2
(1)
DIN 3 function
P2.2.3
(1)
DIN 5 function
P2.2.4
(1)
PID sum point reference
P2.2.5
(1)
I/O B reference selec-
tion
P2.2.6
(1)
Keypad control refer-
ence selection
Danfoss A/S © 2023.02
Min Max
0.00 100.00
0 1
0.00 P2.1.2
Min Max Unit Default
-
0 13 1
-
0 13 10
-
0 13 9
-
0 7 0
-
0 7 1
-
0 7 4
Unit Default ID Description
-
% 25.00 1018
-
0 1019 0 = Wake-up at fall below
wake-up level (P2.1.17)
1 = Wake-up at exceeded
wake-up level (P2.1.17)
-
Hz 10.00 124
ID Description
319 0 = Not used
1 = External fault cc
2 = External fault oc
3 = Run enable
4 = Acc/Dec time selection
5 = CP: I/O terminal (ID125)
6 = CP: Keypad (ID125)
7 = CP: Fieldbus (ID125)
8 = Forward/ Reverse
9 = Jogging frequency (cc)
10 = Fault reset (cc)
11 = Acc/Dec prohibit (cc)
12 = DC braking command
13 = Motor pot. UP (cc)
301 See P2.2.1 except:
13 = Motor pot. DOWN (cc)
330 See P2.2.1 except:
13 = Enable PID reference 2
376 0 = Direct PID output value
1 = AI1+PID output
2 = AI2+PID output
3 = AI3+PID output
4 = AI4+PID output
5 = PID keypad +PID output
6 = Fieldbus+PID output (Process- DataIN3)
7 = Mot.pot.+PID output
343 0 = AI1 1 = AI2
2 = AI3
3 = AI4
121
4 = Keypad reference
5 = Fieldbus reference (FBSpeedReference)
AB296635287482en-000301 / DPD00903 | 65
PID Control Application
