VACON® NX All-in-One
Application Guide
Index
Monitoring value
V1.4
Motor current
V1.5
Motor torque
V1.6
Motor shaft power
V1.7
Motor voltage
V1.8
DC-link voltage
V1.9
Unit temperature
V1.10
Motor temperature
V1.11
Analog input 1
V1.12
Analog input 2
V1.13
DIN 1, 2, 3
V1.14
DIN 4, 5, 6
V1.15
Analog output 1
V1.16
Analog input 3
V1.17
Analog input 4
V1.18
PID Reference
V1.19
PID Actual value
V1.20
PID Error value
V1.21
PID Output
V1.22
Running auxiliary drives
V1.23
Special display for actual value
V1.24
PT-100 temperature
G1.25
Multimonitoring items
V1.26.1
Current
V1.26.2
Torque
V1.26.3
DC-link Voltage
V1.26.4
Status Word
V1.26.5
Fault History
V1.26.6
Motor Current
Danfoss A/S © 2023.02
Pump and Fan Control Application
Unit
Form
ID
A
Varies
3
%
#.#
4
%
#.#
5
V
#.#
6
V
#
7
°C
#
8
%
#.#
9
V/mA
#.##
13
V/mA
#.##
14
-
-
15
-
-
16
V/mA
#.##
26
V/mA
#.##
27
V/mA
#.##
28
%
-
20
%
-
21
%
-
22
%
-
23
-
-
30
V
-
29
ºC
#.#
42
-
-
-
A
Varies
1113
%
#.#
1125
V
-
7
-
-
43
-
-
37
A
-
45
AB296635287482en-000301 / DPD00903 | 133
