VACON® NX All-in-One
Application Guide
Signal
b3
Fault Active
b4
Coast Stop Not Active
b5
Quick Stop Not Active
b6
Switch On Inhibited
b7
Warning
b8
Speed At Reference
b9
Fieldbus Control Active
b10
Speed Reference Reached or Exceeded
b11
Not Used
b12
Drive Running
b13
Drive Ready
b14
Not Used
b15
Not Used
10.633 Condition-based Monitoring
VACON
NXP offers Condition-based Monitoring to identify motor faults at an early stage. Stator Winding Monitoring, Vibration, and
®
Load envelope are supported in this application. Condition-based Monitoring is license protected. To make the Condition-based
Monitoring effective, buy a license key from a Danfoss supplier.
For more detailed information on the commissioning and use of Condition-based Monitoring, refer to the VACON
Monitoring Application Guide.
10.633.1 Introduction to Condition-based Monitoring
Benefits of installing the Condition-based Monitoring firmware are as follows:
•
Reduces unexpected downtime.
•
Optimizes drive or motor working conditions.
•
Eliminates unexpected halts in production.
Condition-based Monitoring regularly checks of the condition and performance of the machine when the drive is in operation, and
detects mechanical, motor, or application failures in advance. Corrective actions can be performed before the process or application
324 | Danfoss A/S © 2023.02
Description
1=The drive is running and ready to release the reference
0=No fault active
1=Fault IS active
0=Coast stop active
1=Coast stop NOT active
0=Emergency stop active
1=Emergency stop NOT active
0=No Inhibit
1=The drive is out of fault and coast / quick stop state
0=NO alarm
1=Alarm IS active
0=Speed actual is NOT equal to speed reference
1=Speed actual is equal to speed reference
0=Fieldbus Control NOT active
1=Fieldbus Control active
Indicate if speed actual is below the limit P2.4.16
0=Speed actual is below the speed limit
1=Speed actual is above the speed limit
Reserved
0=Drive is stopped
1=Drive is running
0=Drive is not ready
1=Drive is ready
Reserved
Reserved
Parameter Descriptions
Condition-based
®
AB296635287482en-000301 / DPD00903
