VACON® NX All-in-One
Application Guide
Bit
DIN StatusWord 1
b10 DIN: B.5
b11 DIN: B.6
b12 DIN: C.1
b13 DIN: C.2
b14 DIN: C.3
b15 DIN: C.4
Table 49: Fault Word 1, ID1172
Bit
Fault
b0 Overcurrent or IGBT
b1 Overvoltage
b2 Undervoltage
b3 Motor stalled
b4 Earth fault
b5 Motor underload
b6 Drive overtemperature
b7 Motor overtemperature
b8 Input phase
b11 Keypad or PC control
b12 Fieldbus
b13 SystemBus
b14 Slot
b15 4 mA
Table 50: Fault Word 2, ID1173
Bit
Fault
b2 Encoder
-
b4
Danfoss A/S © 2023.02
Multi-purpose Control Application
DIN StatusWord 2
DIN: E.3
DIN: E.4
DIN: E.5
DIN: E.6
Comment
F1, F31, F41
F2
F9
F15
F3
F17
F14
F16, F56, F29, F65
F10
F52
F53
F59
F54
F50
Comment
F43
-
